DS8108KIT barcode reader Handheld bar code reader 1D/2D LED Black
Model DS8108KIT
24 specifications
- ConnectivityWired
- TypeHandheld bar code reader
- Weight154 g
- ColourBlack
- Input voltage5 V
- Width66 mm
Overview
- Connectivity
- Wired
- Type
- Handheld bar code reader
- Weight
- 154 g
- Colour
- Black
- Input voltage
- 5 V
- Width
- 66 mm
- Brand
- Zebra
- Category
- Barcode Reader
- Model
- DS8108KIT
- Part number
- DS8108KIT
- Also known as
- Zebra DS8108KIT barcode reader Handheld bar code reader 1D/2D LED Black
Specifications
24 specifications in 7 groups
Scanning
| Specification | Value |
|---|---|
| Type | Handheld bar code reader |
| Scanner type | 1D/2D |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39 |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C. |
| Sensor type | LED |
| Wavelength | 617 nm |
| Tilt reading angle | 0 - 360° |
| Pitch reading angle | 0 - 60° |
| Yaw reading angle | 0 - 60° |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Standard interfaces | RS-232, USB, Keyboard wedge |
| PC connection | RS-232/USB |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| International Protection (IP) code | IP52 |
Power
| Specification | Value |
|---|---|
| Input voltage | 5 V |
| Power consumption | 450 mA |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 66 mm |
| Depth | 107 mm |
| Height | 168 mm |
| Weight | 154 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84716070 |
