Wireless 2D Barcode Scanner, with Stand
Equip

Wireless 2D Barcode Scanner, with Stand

Model 351024EAN 4015867231708

55 specifications
  • Battery1500 mAh
  • ConnectivityWireless
  • TypeHandheld bar code reader
  • Weight187 g
  • ColourBlack
  • Power source typeBattery
See all specifications

Overview

Battery
1500 mAh
Connectivity
Wireless
Type
Handheld bar code reader
Weight
187 g
Colour
Black
Power source type
Battery
Brand
Equip
Model
351024
Part number
351024
EAN / UPC
4015867231708
Also known as
Equip Wireless 2D Barcode Scanner, with Stand

Specifications

55 specifications in 11 groups

Scanning

TypeHandheld bar code reader
Scanner type1D/2D
2D (matrix & stacked) barcodes supportedData Matrix, PDF417, QR Code
Linear (1D) barcodes supportedCodabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN-13, EAN-8, GS1 DataBar, ISBN, ISSN, Industrial 2 of 5, Interleaved 2 of 5, MSI-Plessey, Matrix 2 of 5, Plessey, UPC-A, UPC-E
Sensor typeLED
Trigger modeAuto-induction, Continuous, Manual
Working distance150 cm
Read rate (max)220 reads/s
Tilt reading angle0 - 360°
Pitch reading angle-30 - 30°
Yaw reading angle-35 - 35°

Ports & interfaces

Connectivity technologyWireless
Standard interfacesRF Wireless
Operating frequency2400 MHz
Cable length1.8 m

Performance

Product colourBlack
Housing materialAcrylonitrile butadiene styrene (ABS)
International Protection (IP) codeIP54
Protection featuresDrop proof, Water resistant
Country of originChina

Power

Power source typeBattery
Battery typeBuilt-in battery
Number of batteries supported1
Battery voltage3.7 V
Battery life20 h

Weight & dimensions

Width72 mm
Depth101 mm
Height175 mm
Weight187 g

Packaging data

Cables includedUSB
Charging baseYes
Receiver includedYes
Receiver typeNano receiver
Stand includedYes
Package width150 mm
Package depth207 mm
Package height100 mm
Package weight465 g

Operational conditions

Operating relative humidity (H-H)5 - 95%
Operating temperature (T-T)-20 - 60 °C
Storage temperature (T-T)-45 - 85 °C

Battery

Battery technologyLithium-Ion (Li-Ion)
Battery capacity1500 mAh
Battery capacity5.55 Wh

Technical details

Compliance certificatesCE, RoHS
Sustainability complianceYes

Logistics data

Harmonized System (HS) code8471900090
Master (outer) case gross weight15.5 kg
Master (outer) case height525 mm
Master (outer) case length485 mm
Master (outer) case width440 mm
Products per master (outer) case30 pc(s)

Other features

Linux operating systems supportedYes
Mobile operating systems supportedAndroid, iOS
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 7, Window
