MS3-2D BR
Model MS3-2D BRPart no. MS32DRUSBBRWRBEAN 8447071002816
23 specifications
- Battery2000 mAh
- ConnectivityWireless
- TypeHandheld bar code reader
- ColourBlack
- Power source typeBattery
- Battery technologyLithium
Overview
- Battery
- 2000 mAh
- Connectivity
- Wireless
- Type
- Handheld bar code reader
- Colour
- Black
- Power source type
- Battery
- Battery technology
- Lithium
- Brand
- Premier
- Category
- Barcode Reader
- Model
- MS3-2D BR
- Part numbers
- MS32DRUSBBRWRB, ILM2DUSBBWBCH
- EAN / UPC
- 8447071002816, 8437019184841
- Also known as
- Premier MS3-2D BR Handheld bar code reader 1D/2D CMOS Black
Specifications
23 specifications in 5 groups
Scanning
| Specification | Value |
|---|---|
| Type | Handheld bar code reader |
| Scanner type | 1D/2D |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, Micro QR Code, MicroPDF417, PDF417, QR Code |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, EAN 128, EAN-13, EAN-8, GS1 Databar RSS14, GS1-128 (UCC/EAN-128), ISBN, ISSN, ITF-14, ITF-6, Industrial 2 of 5, Interleaved 2 of 5, JAN-13, JAN-8, MSI, Matrix 2 of 5, Standard 25, UPC-A, UPC-E |
| Sensor type | CMOS |
| Optical sensor resolution (W x H) | 1280 x 800 pixels |
| Scanner resolution | 4 mm |
| Working distance | 3 m |
| Read rate (max) | 120 reads/s |
| Tilt reading angle | 0 - 360° |
| Pitch reading angle | 0 - 39° |
| Yaw reading angle | 0 - 26° |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wireless |
| Standard interfaces | Bluetooth, USB |
| Wireless range | 90 m |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC), Thermoplastic urethane (TPU) |
| International Protection (IP) code | IP42 |
Power
| Specification | Value |
|---|---|
| Power source type | Battery |
| Battery voltage | 3.7 V |
| Charging time | 8 h |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium |
| Battery capacity | 2000 mAh |
