ElitePOS 2D Barcode Scanner
Model ElitePOS 2D Barcode ScannerPart no. 1RL97AAEAN 190781797807
21 specifications
- ConnectivityWired
- TypeHandheld bar code reader
- Weight130 g
- ColourBlack
- Power source typeUSB
- Width125 mm
Overview
- Connectivity
- Wired
- Type
- Handheld bar code reader
- Weight
- 130 g
- Colour
- Black
- Power source type
- USB
- Width
- 125 mm
- Brand
- HP
- Category
- Barcode Reader
- Model
- ElitePOS 2D Barcode Scanner
- Part numbers
- 1RL97AA, 1RL97AT
- EAN / UPC
- 190781797807, 191628730469
- Also known as
- HP ElitePOS 2D Barcode Scanner
Specifications
21 specifications in 7 groups
Scanning
| Specification | Value |
|---|---|
| Type | Handheld bar code reader |
| Scanner type | 2D |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code |
| Linear (1D) barcodes supported | Code 11, Code 128, Code 32, Code 39, Code 93, MSI |
| Read rate (max) | 30 reads/s |
| Tilt reading angle | -360 - 360° |
| Pitch reading angle | -60 - 60° |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Standard interfaces | USB |
| Cable length | 2 m |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Power source type | USB |
| Input voltage | 5 V |
| Power consumption | 500 mA |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 125 mm |
| Depth | 44 mm |
| Height | 76.8 mm |
| Weight | 130 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | 0 - 50 °C |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84716070 |
