Equip USB 2D Omnidirectional Desktop Barcode Scanner
Equip

USB 2D Omnidirectional Desktop Barcode Scanner

1MP

Model 351028EAN 4015867234310

44 specifications
  • ConnectivityWired
  • TypeFixed bar code reader
  • Weight508 g
  • ColourBlack
  • Power source typeUSB
  • Width146 mm
See all specifications

Overview

Connectivity
Wired
Type
Fixed bar code reader
Weight
508 g
Colour
Black
Power source type
USB
Width
146 mm
Brand
Equip
Model
351028
Part number
351028
EAN / UPC
4015867234310
Also known as
Equip USB 2D Omnidirectional Desktop Barcode Scanner, 1MP

Specifications

44 specifications in 10 groups

Scanning

TypeFixed bar code reader
Scanner type1D/2D
2D (matrix & stacked) barcodes supportedData Matrix, PDF417, QR Code
Linear (1D) barcodes supportedCodabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, Interleaved 2 of 5, MSI, Pharmacode, Plessey, UPC-A, UPC-E
Sensor typeLED
Trigger modeAuto-induction, Continuous, Manual
Optical sensor resolution (W x H)1280 x 800 pixels
Scanner resolution9 mm
Working distance70 cm
Read rate (max)150 reads/s

Ports & interfaces

Connectivity technologyWired
Standard interfacesUSB
Cable length1.8 m

Performance

Product colourBlack
Housing materialAcrylonitrile butadiene styrene (ABS)
International Protection (IP) codeIP54
Protection featuresDrop proof, Water resistant
Country of originChina

Power

Power source typeUSB
Input voltage5 V
Input current0.4 A

Weight & dimensions

Width146 mm
Depth114 mm
Height184 mm
Weight508 g

Packaging data

Package width156 mm
Package depth220 mm
Package height165 mm
Package weight850 g

Operational conditions

Operating relative humidity (H-H)5 - 95%
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-40 - 70 °C

Technical details

Compliance certificatesCE, RoHS
Sustainability complianceYes

Logistics data

Harmonized System (HS) code8471900090
Master (outer) case gross weight18.5 kg
Master (outer) case height360 mm
Master (outer) case length830 mm
Master (outer) case width475 mm
Products per master (outer) case20 pc(s)

Other features

Linux operating systems supportedYes
Mobile operating systems supportedAndroid, iOS
Quick start guideYes
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 7, Window
