USB 2D Omnidirectional Desktop Barcode Scanner
Model 351027EAN 4015867234303
42 specifications
- ConnectivityWired
- TypeFixed bar code reader
- Weight295 g
- ColourBlack
- Power source typeUSB
- Width120 mm
Overview
- Connectivity
- Wired
- Type
- Fixed bar code reader
- Weight
- 295 g
- Colour
- Black
- Power source type
- USB
- Width
- 120 mm
- Brand
- Equip
- Category
- Barcode Reader
- Model
- 351027
- Part number
- 351027
- EAN / UPC
- 4015867234303
- Also known as
- Equip USB 2D Omnidirectional Desktop Barcode Scanner
Specifications
42 specifications in 10 groups
Scanning
| Specification | Value |
|---|---|
| Type | Fixed bar code reader |
| Scanner type | 1D/2D |
| 2D (matrix & stacked) barcodes supported | PDF417, QR Code |
| Linear (1D) barcodes supported | AIM-128, Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN-13, EAN-8, ISBN, ISSN, Industrial 2 of 5, Interleaved 2 of 5, MSI-Plessey, Matrix 2 of 5, Standard 2 of 5, UPC-A, UPC-E |
| Sensor type | LED |
| Trigger mode | Auto-induction, Continuous, Manual |
| Optical sensor resolution (W x H) | 640 x 480 pixels |
| Scanner resolution | 1 cm |
| Working distance | 70 cm |
| Read rate (max) | 150 reads/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Standard interfaces | USB |
| Cable length | 1.8 m |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Acrylonitrile butadiene styrene (ABS) |
| International Protection (IP) code | IP54 |
| Protection features | Drop proof, Water resistant |
| Country of origin | China |
Power
| Specification | Value |
|---|---|
| Power source type | USB |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 120 mm |
| Depth | 110 mm |
| Height | 146 mm |
| Weight | 295 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 141 mm |
| Package depth | 210 mm |
| Package height | 132 mm |
| Package weight | 630 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -20 - 70 °C |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
| Sustainability compliance | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8471900090 |
| Master (outer) case gross weight | 15 kg |
| Master (outer) case height | 315 mm |
| Master (outer) case length | 690 mm |
| Master (outer) case width | 445 mm |
| Products per master (outer) case | 20 pc(s) |
Other features
| Specification | Value |
|---|---|
| Linux operating systems supported | Yes |
| Mobile operating systems supported | Android, iOS |
| Quick start guide | Yes |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 7, Window |
