Zyxel Wireless N300
Model Wireless N300Part no. WAP3205 V3EAN 760559123864
44 specifications
- Speed300 Mbit/s
- Weight180 g
- ColourBlack
- 2.4 GHzYes
- Ethernet LAN (RJ-45) ports5
- AC input voltage5 V
Overview
- Speed
- 300 Mbit/s
- Weight
- 180 g
- Colour
- Black
- 2.4 GHz
- Yes
- Ethernet LAN (RJ-45) ports
- 5
- AC input voltage
- 5 V
- Brand
- Zyxel
- Category
- Wireless Access Point
- Model
- Wireless N300
- Part numbers
- WAP3205 V3, WAP3205V3-GB0101F
- EAN / UPC
- 760559123864, 4718937591275, 4718937591534
- Also known as
- Zyxel Wireless N300 300 Mbit/s Black
Specifications
44 specifications in 12 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| Maximum data transfer rate | 300 Mbit/s |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Frequency band | 2.4 GHz |
| Bandwidth | 2.4 GHz |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Automatic channel selection | Yes |
| Auto MDI/MDI-X | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Operating modes | Access Point (AP),Client,Repeater |
Security
| Specification | Value |
|---|---|
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK |
Management features
| Specification | Value |
|---|---|
| Firmware upgradeable | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 5 |
| USB 2.0 ports quantity | 0 |
| WAN connection | Ethernet (RJ-45) |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 5 V |
| Input current | 1 A |
| Power management | Yes |
Design
| Specification | Value |
|---|---|
| Placement | Table, Wall |
| Product colour | Black |
| On/off switch | Yes |
| Reset button | Yes |
| WPS push button | Yes |
| LED indicators | LAN, Power, WLAN |
| Internal | No |
Antenna
| Specification | Value |
|---|---|
| Antennas quantity | 2 |
| Antenna gain level (max) | 7 dBi |
Certificates
| Specification | Value |
|---|---|
| Certification | CE-LVD, BSMI, CE, FCC, NCC |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 142 mm |
| Depth | 95 mm |
| Height | 23 mm |
| Weight | 180 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 288 mm |
| Package depth | 61 mm |
| Package height | 205 mm |
| Package weight | 441 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | LAN (RJ-45) |
| Quick start guide | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Storage relative humidity (H-H) | 10 - 95% |
