AP1200-90 1167 Mbit/s White Power over Ethernet (PoE)
Model AP1200-90Part no. SIL AP1200-90EAN 5060693980244
71 specifications
- Speed1167 Mbit/s
- Weight2.3 kg
- ColourWhite
- 2.4 GHzYes
- Security algorithms256-bit AES, SNMP, SNMPv2, SSH
- Ethernet LAN (RJ-45) ports1
Overview
- Speed
- 1167 Mbit/s
- Weight
- 2.3 kg
- Colour
- White
- 2.4 GHz
- Yes
- Security algorithms
- 256-bit AES, SNMP, SNMPv2, SSH
- Ethernet LAN (RJ-45) ports
- 1
- Brand
- SilverNet
- Category
- Wireless Access Point
- Model
- AP1200-90
- Part number
- SIL AP1200-90
- EAN / UPC
- 5060693980244
- Also known as
- SilverNet AP1200-90 1167 Mbit/s White Power over Ethernet (PoE)
Specifications
71 specifications in 14 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 1167 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Frequency band | 2.412-2.472, 5.1-5.8 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af |
| Cabling technology | 10/100/1000Base-T(X) |
| Automatic channel scanning | Yes |
| Automatic channel selection | Yes |
| Full duplex | Yes |
| Duplex mode auto-negotiation | Yes |
| Auto MDI/MDI-X | Yes |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Modulation | 16-QAM, 256-QAM, BPSK, QPSK |
| Virtual LAN features | IP subnet–based VLAN, Interface-based VLAN, Multiple VXLAN (MUX VLAN), Port-based VLAN, Private VLAN, Tagged VLAN, VLAN Identifier ( VLAN ID) |
| Number of VLAN IDs | 4095 |
| Dynamic Frequency Selection (DFS) | Yes |
| Quality of Service (QoS) support | Yes |
| Transmitting power | 26 dBmW |
| Receiver sensitivity | -82dBm@54Mbps, -74dBm@300Mbps, -72dBm@867Mbps, -68dBm@1.3Gbps |
Security
| Specification | Value |
|---|---|
| Security algorithms | 256-bit AES, SNMP, SNMPv2, SSH |
| MAC address filtering | Yes |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Firmware upgradeable | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Internal RJ-45 ports quantity | 2 |
| USB 2.0 ports quantity | 0 |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| AC input voltage | 100 - 240 V |
| Output voltage | 24-48, 48-56 V |
| Power consumption (typical) | 6 W |
| Power consumption (max) | 16 W |
| Power plug type | Type G |
| Power supply | 15.4 W |
Design
| Specification | Value |
|---|---|
| Placement | Pole |
| Product colour | White |
| International Protection (IP) code | IP67 |
| Reset button | Yes |
| LED indicators | LAN, Signal strength |
Antenna
| Specification | Value |
|---|---|
| Antenna type | Internal |
| Antenna direction type | Directional |
| Antenna features | Integrated antenna |
| Antennas quantity | 1 |
| Antenna gain level (max) | 13 dBi |
| Polarization | Dual polarization |
Performance
| Specification | Value |
|---|---|
| Compatible operating systems | Microsoft Windows, Mac OS, Linux Distributions |
| Minimum system requirements | Internet Explorer, Google Chrome, Mozilla Firefox |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 450 mm |
| Depth | 170 mm |
| Height | 65 mm |
| Weight | 2.3 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 215 mm |
| Package depth | 605 mm |
| Package height | 140 mm |
| Package weight | 2.91 kg |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| PoE adapter included | Yes |
| Mounting kit | Yes |
| Quick start guide | Yes |
| Packaging content | Includes 1 x radio, 1 x PoE injector PSU and 1 x Tilt and Swivel 3 Axis mounting bracket. |
| Bundled software | SilverView Pro Network Management & Monitoring Software |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -20 - 70 °C |
| Storage temperature (T-T) | -40 - 90 °C |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | United Kingdom |
| UK Trade Tariff code | 85176200 |
