Zyxel WAC6503D-S 1300 Mbit/s White Power over Ethernet (PoE)

Zyxel WAC6503D-S 1300 Mbit/s White Power over Ethernet (PoE)

Model WAC6503D-SPart no. 4769EAN 4718937582532

39 specifications
  • Speed1300 Mbit/s
  • Weight982 g
  • ColourWhite
  • 2.4 GHzYes
  • Ethernet LAN (RJ-45) ports2
  • Antenna featuresIntegrated antenna
See all specifications

Overview

Speed
1300 Mbit/s
Weight
982 g
Colour
White
2.4 GHz
Yes
Ethernet LAN (RJ-45) ports
2
Antenna features
Integrated antenna
Brand
Zyxel
Model
WAC6503D-S
Part numbers
4769, WAC6503D-S-EU0101F
EAN / UPC
4718937582532, 4056203588254, 4718937582525, 5057103143870
Also known as
Zyxel WAC6503D-S 1300 Mbit/s White Power over Ethernet (PoE)

Specifications

39 specifications in 12 groups

Features

2.4 GHzYes
5 GHzYes
Maximum data transfer rate1300 Mbit/s
Ethernet LAN data rates10,100,1000 Mbit/s
Frequency band2.4 - 5 GHz
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u
Channel bandwidth80 MHz
MIMOYes
MIMO typeMulti User MIMO
Modulation16-QAM, 256-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, QPSK
Maximum Likelihood Detection (MLD)Yes
Cyclic Shift Diversity (CSD)Yes

Security

Security algorithms802.1x RADIUS, WEP, WPA, WPA2, WPA2-PSK
MAC address filteringYes
Number of SSID supported16

Protocols

DHCP clientYes

Ports & interfaces

Ethernet LAN (RJ-45) ports2

Power

Power over Ethernet (PoE)Yes
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V

Design

Product colourWhite
InternalNo

Antenna

Antenna featuresIntegrated antenna
Antennas quantity6
Antenna gain level (max)6 dBi

Certificates

CertificationFCC Part 15C, FCC Part 15E, ETSI EN 300 328, EN 301 893, LP0002, EN 60601-1-2 FCC Part 15B, EN 301 489-1, EN 301 489-17, EN55022, EN55024, EN61000-3-2/-3, BSMI CNS13438 EN 60950-1, IEC 60950-1, BSMI CNS14336-1f

Weight & dimensions

Width236 mm
Depth227 mm
Height62 mm
Weight982 g

Packaging data

Package width308 mm
Package depth323 mm
Package height127 mm
Package weight1.74 kg

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)10 - 90%

Logistics data

Harmonized System (HS) code85176990
