Zyxel WAC500H 1200 Mbit/s White Power over Ethernet (PoE)

WAC500H 1200 Mbit/s White Power over Ethernet (PoE)

Model WAC500HPart no. WAC500H-EU0101FEAN 4172937615209

50 specifications

Speed1200 Mbit/s
Weight223 g
ColourWhite
2.4 GHzYes
Ethernet LAN (RJ-45) ports3
PlacementWall

See all specifications

Overview

Speed: 1200 Mbit/s
Weight: 223 g
Colour: White
2.4 GHz: Yes
Ethernet LAN (RJ-45) ports: 3
Placement: Wall

Brand: Zyxel
Category: Wireless Access Point
Model: WAC500H
Part numbers: WAC500H-EU0101F, 140110, 140111
EAN / UPC: 4172937615209, 4718937615209
Also known as: Zyxel WAC500H 1200 Mbit/s White Power over Ethernet (PoE)

Specifications

50 specifications in 13 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	1200 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Maximum data transfer rate (5 GHz)	866 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Channel bandwidth	80 MHz
MIMO	Yes
MIMO type	Multi User MIMO
Wi-Fi Multimedia (WMM)/(WME)	Yes
Fast roaming	Yes
VLAN support	Yes
Wireless isolation	Yes
Band steering	Yes
Transmitting power	26 dBmW
Receiver sensitivity	-99 dBm

Security

Specification	Value
Security algorithms	EAP, SNMP, WEP, WPA, WPA2-Enterprise, WPA2-PSK, WPA3
MAC address filtering	Yes
Auto Wireless Distribution System (WDS)	Yes

Management features

Specification	Value
Web-based management	Yes
Command-line interface (CLI)	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	3
DC-in jack	Yes

Power

Specification	Value
Power over Ethernet (PoE)	Yes
AC input frequency	50 - 60 Hz
AC input voltage	100 - 240 V
Input current	0.3 A
Output voltage	12 V
Output current	1 A

Design

Specification	Value
Placement	Wall
Product colour	White

Antenna

Specification	Value
Antenna type	Internal
Antenna gain level (max)	4 dBi

Certificates

Specification	Value
Certification	FCC 15C, FCC 15E; ETSI EN 300 328, EN 301 893; LP0002, EN 60601-1-2 FCC 15B, EN 301 489-1; EN 301 489-17, EN55022, EN55024, EN61000-3-2/-3, BSMI CNS13438 EN 60950-1, IEC 60950-1; BSMI CNS14336-1

Weight & dimensions

Specification	Value
Width	173 mm
Depth	97 mm
Height	29 mm
Weight	223 g

Packaging data

Specification	Value
Package width	195 mm
Package depth	120 mm
Package height	53 mm
Package weight	444 g

Packaging content

Specification	Value
Quantity per pack	1 pc(s)
Mounting kit	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-30 - 70 °C
Storage relative humidity (H-H)	10 - 90%

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
