NWA55BE 5100 Mbit/s White Power over Ethernet (PoE)
Model NWA55BEPart no. NWA55BE-EU0102FEAN 4718937650385
47 specifications
- Speed5100 Mbit/s
- Weight575.6 g
- ColourWhite
- 2.4 GHzYes
- Ethernet LAN (RJ-45) ports1
- PlacementWall
Overview
- Speed
- 5100 Mbit/s
- Weight
- 575.6 g
- Colour
- White
- 2.4 GHz
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Placement
- Wall
- Brand
- Zyxel
- Category
- Wireless Access Point
- Model
- NWA55BE
- Part number
- NWA55BE-EU0102F
- EAN / UPC
- 4718937650385
- Also known as
- Zyxel NWA55BE 5100 Mbit/s White Power over Ethernet (PoE)
Specifications
47 specifications in 12 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 5100 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 688 Mbit/s |
| Maximum data transfer rate (5 GHz) | 4324 Mbit/s |
| Bandwidth | 0.24 GHz |
| Networking standards | IEEE 802.11be, IEEE 802.11ax, IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a, IEEE 802.3at, IEEE 802.3bt |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Fast roaming | Yes |
| VLAN support | Yes |
| Wireless isolation | Yes |
| Band steering | Yes |
| Cellular Coexistence Filter (CCF) | Yes |
| Transmitting power | 26 dBmW |
| Mean time between failures (MTBF) | 631165 h |
| Receiver sensitivity | Min. Rx sensitivity up to -99 dBm |
Security
| Specification | Value |
|---|---|
| Security algorithms | WEP, WPA, WPA2, WPA3, 802.1x RADIUS |
| MAC address filtering | Yes |
| Auto Wireless Distribution System (WDS) | Yes |
Management features
| Specification | Value |
|---|---|
| Command-line interface (CLI) | Yes |
| Cloud-managed | Yes |
| Firmware upgradeable | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power consumption (typical) | 24 W |
Design
| Specification | Value |
|---|---|
| Placement | Wall |
| Product colour | White |
| International Protection (IP) code | IP55 |
Antenna
| Specification | Value |
|---|---|
| Antenna type | External |
| Antenna features | Detachable antenna |
| Antennas quantity | 2 |
| Antenna gain level (max) | 3 dBi |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | Federal Communications Commission (FCC) |
| Certification | FCC Part 15C, FCC Part 15E, FCC Part 2.1091, ETSI EN 300 328, EN 301 893, Draft EN 303 687, EN 50385, EN 50665, EN IEC 62311, LP0002, FCC Part 15B, EN 301 489-1, EN 301 489-17, EN55032, EN55035, EN61000-3-2/-3, EN60601-1-2, BSMI CNS15936, EN 62368-1, IEC 62368-1, BSMI CNS15598-1 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 308 mm |
| Depth | 136.4 mm |
| Height | 49.6 mm |
| Weight | 575.6 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 221 mm |
| Package depth | 188 mm |
| Package height | 59 mm |
| Package weight | 984.5 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -25 - 65 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 10 - 90% |
