NWA3166 wireless access point 300 Mbit/s Power over Ethernet (PoE)
Model NWA3166EAN 760559116484
20 specifications
- Speed300 Mbit/s
- Weight420 g
- 2.4 GHzYes
- Security algorithmsWPA, WPA2
- Ethernet LAN (RJ-45) ports1
- InternalNo
Overview
- Speed
- 300 Mbit/s
- Weight
- 420 g
- 2.4 GHz
- Yes
- Security algorithms
- WPA, WPA2
- Ethernet LAN (RJ-45) ports
- 1
- Internal
- No
- Brand
- Zyxel
- Category
- Wireless Access Point
- Model
- NWA3166
- Part number
- NWA3166
- EAN / UPC
- 760559116484, 7605591164846
- Also known as
- Zyxel NWA3166 wireless access point 300 Mbit/s Power over Ethernet (PoE)
Specifications
20 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 300 Mbit/s |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Throughput data rate | 110 Mbit/s |
| Frequency band | 2.4, 5 GHz |
| Modulation | 16-QAM, 64-QAM, DQPSK, QPSK |
Security
| Specification | Value |
|---|---|
| Security algorithms | WPA, WPA2 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power supply type | 12 V DC, 1.5 A |
Design
| Specification | Value |
|---|---|
| Internal | No |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 138.5 x 198.5 x 47.5 mm |
| Weight | 420 g |
Other features
| Specification | Value |
|---|---|
| Compliance industry standards | IEEE 802.3, IEEE 802.3u, IEEE 802.11a, IEEE 802.11 b/g, 802.3af |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
