NWA130BE BE11K 2x2 MU-MIMO

Model NWA130BE BE11K 2x2 MU-MIMOPart no. NWA130BEEAN 760559131050

107 specifications

ProcessorQualcomm Networking Pro 1210
Speed11000 Mbit/s
Weight808 g
ColourWhite
2.4 GHzYes
Ethernet LAN (RJ-45) ports2

See all specifications

Overview

Processor: Qualcomm Networking Pro 1210
Speed: 11000 Mbit/s
Weight: 808 g
Colour: White
2.4 GHz: Yes
Ethernet LAN (RJ-45) ports: 2

Brand: Zyxel
Category: Wireless Access Point
Model: NWA130BE BE11K 2x2 MU-MIMO
Part number: NWA130BE
EAN / UPC: 760559131050
Also known as: Zyxel NWA130BE BE11K 2x2 MU-MIMO 11000 Mbit/s White Power over Ethernet (PoE)

Specifications

107 specifications in 16 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
6 GHz	Yes
Maximum data transfer rate	11000 Mbit/s
Maximum data transfer rate (2.4 GHz)	688 Mbit/s
Maximum data transfer rate (5 GHz)	4324 Mbit/s
Maximum data transfer rate (6 GHz)	5764 Mbit/s
Ethernet LAN data rates	10,100,300,1000,1200,2000,2500 Mbit/s
Frequency band	6425 GHz
Bandwidth	320 GHz
Networking standards	IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be
Cabling technology	10/100/1000Base-T(X)
Number of users	100 user(s)
Channels quantity	6 channels
Channel bandwidth	320 MHz
Automatic channel scanning	Yes
Automatic channel selection	Yes
Full duplex	Yes
Duplex mode auto-negotiation	Yes
Tunnel forwarding	Yes
Auto MDI/MDI-X	Yes
MIMO	Yes
MIMO type	Multi User MIMO
Spatial streams	2x2
Wi-Fi roaming	Yes
Fast roaming	Yes
WLAN channel features	WLAN channel management
VLAN support	Yes
Virtual LAN features	Interface-based VLAN, Multicast VLAN
Wireless isolation	Yes
Band steering	Yes
Dynamic Frequency Selection (DFS)	Yes
Quality of Service (QoS) support	Yes
BeamForming	Yes
Trusted Platform Module (TPM)	Yes

Security

Specification	Value
Security algorithms	EAP, WPA2, WPA2-AES, WPA2-CCMP, WPA2-EAP, WPA2-Enterprise, WPA2-Enterprise-PEAP, WPA2-PSK, WPA2-Personal, WPA2-RADIUS, WPA2-TKIP, WPA3, WPA3-EAP, WPA3-Enterprise, WPA3-PSK, WPA3-Personal
MAC address filtering	Yes
IP address filtering	No
Service Set Identifier (SSID) features	Hidden SSID, Multiple SSIDs, SSID broadcast
Number of SSID supported	8
DHCP snooping	Yes
IGMP snooping	Yes
Auto Wireless Distribution System (WDS)	Yes
Wireless Intrusion Detection System (WIDS)	Yes
Wireless Intrusion Prevention System (WIPS)	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes

Protocols

Specification	Value
Universal Plug and Play (UPnP)	Yes
DHCP server	Yes
DHCP client	Yes
IPv4 & IPv6 features	IPv4/IPv6 access-control list (ACL)

Management features

Specification	Value
Web-based management	Yes
Command-line interface (CLI)	No
Syslog	No
Firmware upgradeable	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	1
USB connector type	USB Type-C
DC-in jack	Yes

Power

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) type supported	Active PoE
DC voltage range	12 V
Input current	2 A
Power consumption (typical)	24 W
Power consumption (max)	24 W
Power supply	12 W

Design

Specification	Value
Placement	Ceiling, Wall
Product colour	White
Housing material	Aluminium, Metal, Plastic
Cable lock slot	Yes
Cable lock slot type	Kensington
On/off switch	No
Reset button	Yes
WPS push button	No
LED indicators	LAN, Status, WLAN, Wi-Fi
Market segment	Business
Recommended usage	Indoor

Antenna

Specification	Value
Antenna type	Internal
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Antennas quantity	6
Antenna gain level (max)	4 dBi
Polarization	Dual polarization

Performance

Specification	Value
Built-in processor	Yes
Processor model	Qualcomm Networking Pro 1210

Certificates

Specification	Value
Compliance certificates	CE, China RoHS, cTUVus
Certification	Radio FCC Part 15C FCC Part 15E FCC Part 2.1091 ETSI EN 300 328 EN 301 893 Draft EN 303 687 EN 50385 EN 50665 EN IEC 62311,LP0002 EMC FCC Part 15B EN 301 489-1 EN 301 489-17 EN55032 EN55035 EN61000-3-2/-3 EN60601-1-2 BSMI CNS15936 Safety EN 62368-1 IEC 62368-1 BSMI CNS15598-1

Weight & dimensions

Specification	Value
Width	250 mm
Depth	160 mm
Height	47 mm
Weight	808 g

Packaging data

Specification	Value
Package width	280 mm
Package depth	181 mm
Package height	66 mm
Package weight	1.03 kg
Package type	Box

Packaging content

Specification	Value
Quantity per pack	1 pc(s)
AC adapter included	No
PoE adapter included	No
Mounting kit	Yes
Quick start guide	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 95%
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	10 - 90%

Sustainability

Specification	Value
Sustainability compliance	Yes

Logistics data

Specification	Value
Country of origin	China
Warranty period	5 year(s)
