Zyxel 802.11ac Dual-Radio Ceiling Mount PoE Access Point

Zyxel 802.11ac Dual-Radio Ceiling Mount PoE Access Point

Model NWA1123-ACv2Part no. NWA1123-ACV2-EU0101FEAN 4718937591862

48 specifications
  • Speed1200 Mbit/s
  • Weight300 g
  • ColourWhite
  • 2.4 GHzYes
  • Ethernet LAN (RJ-45) ports1
  • PlacementCeiling, Wall
See all specifications

Overview

Speed
1200 Mbit/s
Weight
300 g
Colour
White
2.4 GHz
Yes
Ethernet LAN (RJ-45) ports
1
Placement
Ceiling, Wall
Brand
Zyxel
Model
NWA1123-ACv2
Part numbers
NWA1123-ACV2-EU0101F, 4613
EAN / UPC
4718937591862
Also known as
Zyxel 802.11ac Dual-Radio Ceiling Mount PoE Access Point

Specifications

48 specifications in 12 groups

Features

2.4 GHzYes
5 GHzYes
Maximum data transfer rate1200 Mbit/s
Ethernet LAN data rates10,100,1000 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u
MIMOYes
MIMO typeMulti User MIMO
Modulation16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DQPSK, QPSK
Fast roamingYes
VLAN supportYes
Receiver sensitivity2.4 GHz: - 802.11b/g, -99 dBm - 802.11n/20 MHz, -93 dBm - 802.11n/40 MHz, -88 dBm 5 GHz: - 802.11a, -95 dBm - 802.11ac/n/20 MHz, -94 dBm - 802.11ac/n/40 MHz, -92 dBm - 802.11ac/80 MHz, -89 dBm

Security

Security algorithmsEAP-AKA, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, WEP, WPA, WPA2-Enterprise, WPA2-PSK
MAC address filteringYes
Number of SSID supported16
Auto Wireless Distribution System (WDS)Yes

Protocols

DHCP clientYes
Management protocolsZAC, SNMP, CLI, AP

Ports & interfaces

Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity0
DC-in jackYes

Power

Power over Ethernet (PoE)Yes
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Input current0.3 A
Output voltage12 V
Output current1 A
Power consumption (typical)9 W

Design

PlacementCeiling, Wall
Product colourWhite
Reset buttonYes
InternalNo

Antenna

Antenna featuresIntegrated antenna
Antennas quantity2

Certificates

CertificationFCC Part 15C, FCC Part 15E; ETSI EN 300 328, EN 301 893; LP0002, EN 60601-1-2, FCC Part 15B, EN 301 489-1; EN 301 489-17, EN55022, EN55024, EN61000-3-2/-3, BSMI CNS13438, EN 60950-1, IEC 60950-1; BSMI CNS14336-1

Weight & dimensions

Width130 mm
Depth130 mm
Height54.7 mm
Weight300 g

Packaging data

Package width278 mm
Package depth209 mm
Package height72 mm
Package weight700 g

Packaging content

AC adapter includedYes
Mounting kitYes

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-30 - 70 °C
Storage relative humidity (H-H)10 - 90%
