Zyxel NWA1123-ACHD-EU010 wireless access point 1300 Mbit/s White Power over Ethernet (PoE)

Zyxel NWA1123-ACHD-EU010 wireless access point 1300 Mbit/s White Power over Ethernet (PoE)

Model NWA1123-ACHD-EU010

47 specifications
  • Speed1300 Mbit/s
  • Weight750 g
  • ColourWhite
  • 2.4 GHzYes
  • Number of SSID supported16
  • Ethernet LAN (RJ-45) ports2
See all specifications

Overview

Speed
1300 Mbit/s
Weight
750 g
Colour
White
2.4 GHz
Yes
Number of SSID supported
16
Ethernet LAN (RJ-45) ports
2
Brand
Zyxel
Model
NWA1123-ACHD-EU010
Part number
NWA1123-ACHD-EU010
Also known as
Zyxel NWA1123-ACHD-EU010 wireless access point 1300 Mbit/s White Power over Ethernet (PoE)

Specifications

47 specifications in 12 groups

Features

2.4 GHzYes
5 GHzYes
Maximum data transfer rate1300 Mbit/s
Ethernet LAN data rates10,100,1000 Mbit/s
Throughput data rate900 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u
MIMOYes
MIMO typeMulti User MIMO
Modulation16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DBQSK, QPSK
VLAN supportYes
Maximal-Ratio Combining (MRC)Yes
Maximum Likelihood Detection (MLD)Yes
Cyclic Shift Diversity (CSD)Yes
Quality of Service (QoS) supportYes

Security

Security algorithms802.1x RADIUS, EAP, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA2-Enterprise, WPA2-PSK
Number of SSID supported16

Protocols

DHCP clientYes
Management protocolsSNMP v2c/v3

Management features

Command-line interface (CLI)Yes
Firmware upgradeableYes

Ports & interfaces

Ethernet LAN (RJ-45) ports2
USB 2.0 ports quantity0
DC-in jackYes

Power

Power over Ethernet (PoE)Yes
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Output voltage12 V
Output current2 A
Power consumption (typical)15.5 W

Design

PlacementCeiling, Wall
Product colourWhite
Cable lock slotYes
Cable lock slot typeKensington
LED indicatorsYes

Antenna

Antenna typeInternal
Antenna gain level (max)3 dBi

Certificates

CertificationFCC Part 15C FCC Part 15E ETSI EN 300 328 EN 301 893 LP0002 EN 60601-1-2 FCC Part 15B EN 301 489-1 EN 301 489-17 EN55032 EN55024 EN61000-3-2/-3 BSMI CNS13438 EN 60950-1 IEC 60950-1 BSMI CNS14336-1

Weight & dimensions

Width211 mm
Depth223 mm
Height39 mm
Weight750 g

Packaging content

PoE adapter includedYes
Mounting kitYes

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)-20 - 50 °C
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)10 - 90%
