Zyxel NWA1123 AC Pro NebulaFlex

NWA1123 AC Pro NebulaFlex

Model NWA1123 AC Pro NebulaFlexPart no. NWA1123ACPRO-EU0104FEAN 4718937604548

32 specifications

Speed1300 Mbit/s
ColourWhite
2.4 GHzYes
Ethernet LAN (RJ-45) ports2
AC input frequency50 Hz
PlacementCeiling, Wall

See all specifications

Overview

Speed: 1300 Mbit/s
Colour: White
2.4 GHz: Yes
Ethernet LAN (RJ-45) ports: 2
AC input frequency: 50 Hz
Placement: Ceiling, Wall

Brand: Zyxel
Category: Wireless Access Point
Model: NWA1123 AC Pro NebulaFlex
Part number: NWA1123ACPRO-EU0104F
EAN / UPC: 4718937604548
Also known as: Zyxel NWA1123 AC Pro NebulaFlex 1300 Mbit/s White

Specifications

32 specifications in 11 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	1300 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3au, IEEE 802.3az, IEEE 802.3u
Channel bandwidth	80 MHz
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DPSK, DQPSK, QPSK
Wi-Fi Multimedia (WMM)/(WME)	Yes
VLAN support	Yes
Wireless isolation	Yes

Security

Specification	Value
Security algorithms	802.1x RADIUS, EAP-AKA, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, SNMP, SSH, WEP, WPA, WPA2-Enterprise, WPA2-PSK
MAC address filtering	Yes
Service Set Identifier (SSID) features	SSID broadcast on/off
Number of SSID supported	16

Protocols

Specification	Value
DHCP client	Yes

Management features

Specification	Value
Firmware upgradeable	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2

Power

Specification	Value
AC input frequency	50 Hz
AC input voltage	100 - 240 V

Design

Specification	Value
Placement	Ceiling, Wall
Product colour	White

Antenna

Specification	Value
Antenna type	Internal
Antennas quantity	3
Antenna gain level (max)	5 dBi

Certificates

Specification	Value
Certification	FCC part 15C, FCC part 15E, ETSI EN 300 328, EN 301 893, LP0002 FCC part 15B, EN 301 489-1, EN 301 489-17, EN55022, EN55024, EN61000-3-2/-3, BSMI CNS13438 EN 60950-1, IEC 60950-1, BSMI CNS14336-1 FCC part 15B, EN 301 489-1, EN 301 489-17, EN55022, EN55024, EN61000-3-2/-3, BSMI CNS13438 EN 60950-1, I

Weight & dimensions

Specification	Value
Width	203.9 mm
Depth	191.7 mm
Height	34.7 mm

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	10 - 90%
