Zyxel NWA1123-AC PRO 3-pack

Zyxel NWA1123-AC PRO 3-pack

Model NWA1123-AC PRO 3-packPart no. NWA1123ACPRO-EU0102FEAN 4718937595297

41 specifications
  • Speed1300 Mbit/s
  • Weight445 g
  • ColourWhite
  • 2.4 GHzYes
  • Ethernet LAN (RJ-45) ports2
  • PlacementCeiling, Wall
See all specifications

Overview

Speed
1300 Mbit/s
Weight
445 g
Colour
White
2.4 GHz
Yes
Ethernet LAN (RJ-45) ports
2
Placement
Ceiling, Wall
Brand
Zyxel
Model
NWA1123-AC PRO 3-pack
Part number
NWA1123ACPRO-EU0102F
EAN / UPC
4718937595297
Also known as
Zyxel NWA1123-AC PRO 3-pack 1300 Mbit/s White Power over Ethernet (PoE)

Specifications

41 specifications in 14 groups

Features

2.4 GHzYes
5 GHzYes
Maximum data transfer rate1300 Mbit/s
Ethernet LAN data rates10,100,1000 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3au, IEEE 802.3az, IEEE 802.3u
Channel bandwidth80 MHz
Modulation16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DPSK, DQPSK, QPSK
Wi-Fi Multimedia (WMM)/(WME)Yes
VLAN supportYes
Wireless isolationYes

Security

Security algorithms802.1x RADIUS, EAP-AKA, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, SNMP, SSH, WEP, WPA, WPA2-Enterprise, WPA2-PSK
MAC address filteringYes
Service Set Identifier (SSID) featuresSSID broadcast on/off
Number of SSID supported16

Protocols

DHCP clientYes

Management features

Firmware upgradeableYes

Ports & interfaces

Ethernet LAN (RJ-45) ports2
DC-in jackYes

Power

Power over Ethernet (PoE)Yes
AC input frequency50 Hz
AC input voltage100 - 240 V

Design

PlacementCeiling, Wall
Product colourWhite
InternalNo

Antenna

Antennas quantity3
Antenna gain level (max)5 dBi

Certificates

CertificationFCC part 15C, FCC part 15E, ETSI EN 300 328, EN 301 893, LP0002 FCC part 15B, EN 301 489-1, EN 301 489-17, EN55022, EN55024, EN61000-3-2/-3, BSMI CNS13438 EN 60950-1, IEC 60950-1, BSMI CNS14336-1 FCC part 15B, EN 301 489-1, EN 301 489-17, EN55022, EN55024, EN61000-3-2/-3, BSMI CNS13438 EN 60950-1, I

Weight & dimensions

Width203.9 mm
Depth191.7 mm
Height34.7 mm
Weight445 g

Packaging data

Package width240 mm
Package depth235 mm
Package height100 mm
Package weight1.21 kg

Packaging content

Quantity per pack3 pc(s)

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)10 - 90%

Logistics data

Harmonized System (HS) code85176990
