Zyxel NWA1123-AC 300 Mbit/s White Power over Ethernet (PoE)
Model NWA1123-ACPart no. NWA1123-AC-EU0101EAN 7605591212042
34 specifications
- Speed300 Mbit/s
- Weight260 g
- ColourWhite
- 2.4 GHzYes
- Ethernet LAN (RJ-45) ports1
- Antennas quantity2
Overview
- Speed
- 300 Mbit/s
- Weight
- 260 g
- Colour
- White
- 2.4 GHz
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Antennas quantity
- 2
- Brand
- Zyxel
- Category
- Wireless Access Point
- Model
- NWA1123-AC
- Part numbers
- NWA1123-AC-EU0101, NWA1123-AC-EU0101F
- EAN / UPC
- 7605591212042, 012303195345, 667184111832, 4055895708049 +7 more
- Also known as
- Zyxel NWA1123-AC 300 Mbit/s White Power over Ethernet (PoE)
Specifications
34 specifications in 11 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 300 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Frequency band | 2.4, 5 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u |
| Channels quantity | 2 channels |
| Channel bandwidth | 80 MHz |
| Modulation | 256-QAM |
| VLAN support | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | 802.1x RADIUS, EAP-FAST, EAP-SIM, EAP-TLS, EAP-TTLS, SSID, WEP, WPA2, WPA2-PSK |
| MAC address filtering | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| Management protocols | SNMP, CLI |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power consumption (typical) | 7 W |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Internal | No |
Antenna
| Specification | Value |
|---|---|
| Antennas quantity | 2 |
| Antenna gain level (max) | 5 dBi |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC, |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 130 mm |
| Depth | 130 mm |
| Height | 54.5 mm |
| Weight | 260 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 282 mm |
| Package depth | 207 mm |
| Package height | 71 mm |
| Package weight | 640 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Storage relative humidity (H-H) | 10 - 90% |
