Zyxel NWA-1100 100 Mbit/s Power over Ethernet (PoE)

NWA-1100 100 Mbit/s Power over Ethernet (PoE)

Model NWA-1100Part no. 2443EAN 5052178404123

25 specifications

Speed100 Mbit/s
Weight180 g
Security algorithmsPEAP
Ethernet LAN (RJ-45) ports1
Power over Ethernet (PoE)Yes
InternalNo

See all specifications

Overview

Speed: 100 Mbit/s
Weight: 180 g
Security algorithms: PEAP
Ethernet LAN (RJ-45) ports: 1
Power over Ethernet (PoE): Yes
Internal: No

Brand: Zyxel
Category: Wireless Access Point
Model: NWA-1100
Part numbers: 2443, 91-005-244003B, ZYXNWA-1100
EAN / UPC: 5052178404123, 778890666377, 4718937509539
Also known as: Zyxel NWA-1100 100 Mbit/s Power over Ethernet (PoE)

Specifications

25 specifications in 10 groups

Features

Specification	Value
Maximum data transfer rate	100 Mbit/s
Frequency band	2.412 - 2.472 GHz
Modulation	16-QAM, 64-QAM, CCK, DQPSK, QPSK

Security

Specification	Value
Security algorithms	PEAP

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1

Power

Specification	Value
Power over Ethernet (PoE)	Yes
AC input voltage	12 V
Power consumption (typical)	7.8 W

Design

Specification	Value
Internal	No

Certificates

Specification	Value
Certification	EMC: - FCC Part 15B - EN 301 489-17 V1.2.1: 08-2002 - EN 301 489-1 V1.5.1: 11-2004 - ICES-003 Radio: - FCC Part 15C 15.247 - ETSI EN 300 328 - DGT LP0002 - Industry Canada RSS-210 - CISPR22 - SRRC & CCC

Weight & dimensions

Specification	Value
Dimensions (WxDxH)	152 x 92 x 45 mm
Weight	180 g

Packaging data

Specification	Value
Package weight	750 g

Other features

Specification	Value
Supported data transfer rates	IEEE 802.11b: CCK: 11/ 5.5Mbps, DQPSK: 2Mbps, DBPSK: 1 Mbps; IEEE 802.11g: 64-QAM: 54/ 48Mbps, 16-QAM: 36/ 24Mbps, QPSK: 18/ 12Mbps, BPSK: 9/ 6Mbps
Indoor range	150m
Outdoor range	500m
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3af
Package dimensions (WxDxH)	275 x 147 x 100 mm
Safety	EN 60950-1
I/O ports	1 x RJ-45
Wireless standard	IEEE 802.11 b/g

Operational conditions

Specification	Value
Operating relative humidity (H-H)	20 - 90%
Operating temperature (T-T)	10 - 50 °C
Storage temperature (T-T)	-30 - 60 °C
Storage relative humidity (H-H)	10 - 90%
