Zyxel AC3000 Tri-Band WiFi System
Model AC3000 Tri-Band WiFi SystemPart no. WSQ60-EU0201FEAN 4718937602520
38 specifications
- Memory4000 MB
- Speed1733 Mbit/s
- Weight740 g
- ColourGrey
- 2.4 GHzYes
- Ethernet LAN (RJ-45) ports3
Overview
- Memory
- 4000 MB
- Speed
- 1733 Mbit/s
- Weight
- 740 g
- Colour
- Grey
- 2.4 GHz
- Yes
- Ethernet LAN (RJ-45) ports
- 3
- Brand
- Zyxel
- Category
- Wireless Access Point
- Model
- AC3000 Tri-Band WiFi System
- Part numbers
- WSQ60-EU0201F, WSQ60-EU0101F
- EAN / UPC
- 4718937602520, 4718937606337
- Also known as
- Zyxel AC3000 Tri-Band WiFi System 1733 Mbit/s Grey
Specifications
38 specifications in 10 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 1733 Mbit/s |
| Wi-Fi data rate (max) | 1733 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Auto MDI/MDI-X | Yes |
| Modulation | 256-QAM |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 3 |
| USB 2.0 ports quantity | 1 |
| WAN connection | Ethernet (RJ-45) |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 12 V |
| Input current | 3 A |
| Power consumption (typical) | 25 W |
Design
| Specification | Value |
|---|---|
| Placement | Ceiling, Table, Wall |
| Product colour | Grey |
| Reset button | Yes |
| LED indicators | Status |
| Internal | Yes |
Antenna
| Specification | Value |
|---|---|
| Antenna features | Integrated antenna |
| Antennas quantity | 9 |
Performance
| Specification | Value |
|---|---|
| Flash memory | 512 MB |
| Internal memory | 4000 MB |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 236 mm |
| Depth | 178 mm |
| Height | 51.5 mm |
| Weight | 740 g |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 2 pc(s) |
| AC adapter included | Yes |
| Cables included | LAN (RJ-45) |
| Mounting kit | Yes |
| Quick start guide | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Storage relative humidity (H-H) | 10 - 95% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
