TP-Link TL-WA701ND wireless access point 150 Mbit/s White Power over Ethernet (PoE)

TL-WA701ND wireless access point 150 Mbit/s White Power over Ethernet (PoE)

Model TL-WA701NDEAN 4923113116344

38 specifications

Speed150 Mbit/s
ColourWhite
2.4 GHzYes
Ethernet LAN (RJ-45) ports1
PlacementTable
Width181 mm

See all specifications

Overview

Speed: 150 Mbit/s
Colour: White
2.4 GHz: Yes
Ethernet LAN (RJ-45) ports: 1
Placement: Table
Width: 181 mm

Brand: TP-Link
Category: Wireless Access Point
Model: TL-WA701ND
Part number: TL-WA701ND
EAN / UPC: 4923113116344, 115971261463, 163121435110, 168141653872 +12 more
Also known as: TP-Link TL-WA701ND wireless access point 150 Mbit/s White Power over Ethernet (PoE)

Specifications

38 specifications in 12 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	No
Maximum data transfer rate	150 Mbit/s
Wi-Fi data rate (max)	150 Mbit/s
Ethernet LAN data rates	10,100 Mbit/s
Frequency band	2.4 - 2.4835 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Auto MDI/MDI-X	Yes
Modulation	16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
Maximum indoor range	30 m
Receiver sensitivity	135M: -69dBm@10% PER 54M: -73dBm@10% PER 11M: -85dBm@8% PER 6M: -89dBm@10% PER 1M: -90dBm@8% PER

Security

Specification	Value
Security algorithms	128-bit WEP, 152-bit WEP, 64-bit WEP, SSID, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
MAC address filtering	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0

Power

Specification	Value
Power over Ethernet (PoE)	Yes
Output voltage	9 V
Output current	0.6 A

Design

Specification	Value
Placement	Table
Product colour	White
Reset button	Yes
LED indicators	Yes
Internal	No

Antenna

Specification	Value
Antennas quantity	1
Antenna gain level (max)	5 dBi

Performance

Specification	Value
Compatible operating systems	Windows 98SE, NT, 2000, XP, Vista, 7 MAC OS NetWare UNIX, Linux

Certificates

Specification	Value
Certification	RoHS, FCC

Weight & dimensions

Specification	Value
Width	181 mm
Depth	125 mm
Height	36 mm

Packaging data

Specification	Value
CD manual	Yes

Packaging content

Specification	Value
AC adapter included	Yes
Cables included	LAN (RJ-45)
Quick start guide	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
