TL-WA5210G wireless access point 54 Mbit/s Power over Ethernet (PoE)
Model TL-WA5210GEAN 8459730514882
25 specifications
- Speed54 Mbit/s
- 2.4 GHzYes
- Ethernet LAN (RJ-45) ports1
- InternalNo
- Antenna gain level (max)12 dBi
- Dimensions (WxDxH)265 x 120 x 83 mm
Overview
- Speed
- 54 Mbit/s
- 2.4 GHz
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Internal
- No
- Antenna gain level (max)
- 12 dBi
- Dimensions (WxDxH)
- 265 x 120 x 83 mm
- Brand
- TP-Link
- Category
- Wireless Access Point
- Model
- TL-WA5210G
- Part number
- TL-WA5210G
- EAN / UPC
- 8459730514882, 163120541256, 746320533674, 845973051488 +2 more
- Also known as
- TP-Link TL-WA5210G wireless access point 54 Mbit/s Power over Ethernet (PoE)
Specifications
25 specifications in 9 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| Maximum data transfer rate | 54 Mbit/s |
| Frequency band | 2.4 - 2.4835 GHz |
| Modulation | DBPSK, DSSS, OFDM, QPSK |
| Receiver sensitivity | 802.11g 54M: -76dBm 48M: -78dBm 36M: -82dBm 12M: -91dBm 9M:-92dBm, 802.11b 11M:-90dBm 5.5M:-92dBm 1M:-98dBm |
Security
| Specification | Value |
|---|---|
| Security algorithms | 128-bit WEP, 64-bit WEP, WPA, WPA-AES, WPA-PSK, WPA2, WPA2-PSK |
| MAC address filtering | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power requirements | 12VDC / 1.0A |
Design
| Specification | Value |
|---|---|
| Internal | No |
Antenna
| Specification | Value |
|---|---|
| Antenna gain level (max) | 12 dBi |
| Antenna connector type | RP-SMA |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 265 x 120 x 83 mm |
Other features
| Specification | Value |
|---|---|
| Supported data transfer rates | 54/48/36/24/18/12/11/9/6/5.5/2/1 Mbps |
| Compliance industry standards | IEEE 802.11g, IEEE 802.11b |
| Horizontal beam width | 30° |
| Maximum operating distance | 50000 m |
| Networking features | Fast Ethernet |
| Transmit power range | 20/27 dBm |
| Vertical beam width | 60° |
| Connectivity LEDs | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -30 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
