TP-Link EAP683 LR: Full Specifications

Overview

Speed: 6000 Mbit/s
Colour: White
2.4 GHz: Yes
Security algorithms: HTTPS, SNMP, SNMPv2, SNMPv3, SSH
Ethernet LAN (RJ-45) ports: 1
Placement: Ceiling, Wall

Brand: TP-Link
Category: Wireless Access Point
Model: EAP683 LR
Part number: EAP683 LR
EAN / UPC: 840030711893, 4895252506464, 4895252506471
Also known as: TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point

Specifications

51 specifications in 12 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
6 GHz	No
Maximum data transfer rate	6000 Mbit/s
Maximum data transfer rate (2.4 GHz)	1148 Mbit/s
Maximum data transfer rate (5 GHz)	4804 Mbit/s
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Frequency band	2.4 - 6 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
Number of users	510 user(s)
Automatic channel scanning	Yes
Automatic channel selection	Yes
MIMO	Yes
MIMO type	Multi User MIMO
Fast roaming	Yes
VLAN support	Yes
Rate limiting	Yes
Band steering	Yes
Airtime Fairness (ATF)	Yes
Quality of Service (QoS) support	Yes
BeamForming	Yes

Security

Specification	Value
Security algorithms	HTTPS, SNMP, SNMPv2, SNMPv3, SSH
MAC address filtering	Yes
Service Set Identifier (SSID) features	Multiple SSIDs
Access Control List (ACL)	Yes

Management features

Specification	Value
Syslog	Yes
Firmware upgradeable	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0
DC-in jack	Yes

Power

Specification	Value
Power over Ethernet (PoE)	Yes
DC voltage range	12 V

Design

Specification	Value
Placement	Ceiling, Wall
Product colour	White
Reset button	Yes
LED indicators	Yes

Antenna

Specification	Value
Antenna type	Internal
Antenna direction type	Omni-directional
Antenna gain level (max)	5 dBi

Certificates

Specification	Value
Compliance certificates	CE, RoHS

Weight & dimensions

Specification	Value
Width	220 mm
Depth	220 mm
Height	32.5 mm

Packaging data

Specification	Value
Package type	Box

Packaging content

Specification	Value
Quantity per pack	1 pc(s)
Mounting kit	Yes
Quick start guide	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
