TP-Link EAP653 (5-pack): Full Specifications

Overview

Speed: 2976 Mbit/s
Colour: White
2.4 GHz: Yes
Ethernet LAN (RJ-45) ports: 1
Placement: Ceiling, Wall
Antenna type: Internal

Brand: TP-Link
Category: Wireless Access Point
Model: EAP653 (5-pack)
Part number: EAP653(5-PACK)
EAN / UPC: 4895252505306
Also known as: TP-Link Omada AX3000 Ceiling Mount WiFi 6 Access Point (5-pack)

Specifications

53 specifications in 11 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
6 GHz	No
Maximum data transfer rate	2976 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Maximum data transfer rate (5 GHz)	2402 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Frequency band	2.4 - 5 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h
Cabling technology	10/100/1000Base-T(X)
Number of users	250 user(s)
Automatic channel scanning	Yes
Automatic channel selection	Yes
MIMO	Yes
MIMO type	Multi User MIMO
Spread spectrum method	OFDMA
Fit AP mode features	Mesh networking
VLAN support	Yes
Rate limiting	Yes
Flow control support	Yes
Band steering	Yes
Airtime Fairness (ATF)	Yes
Quality of Service (QoS) support	Yes
BeamForming	Yes
Transmitting power (CE)	27 dBm
Transmitting power (FCC)	22 dBm

Security

Specification	Value
Security algorithms	HTTPS, SNMP, SNMPv2, SNMPv3, SSH, WPA, WPA2, WPA3
MAC address filtering	Yes
Access Control List (ACL)	Yes

Management features

Specification	Value
Web-based management	Yes
Syslog	Yes
Firmware upgradeable	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0
DC-in jack	Yes

Power

Specification	Value
Power over Ethernet (PoE)	Yes
DC voltage range	12 V

Design

Specification	Value
Placement	Ceiling, Wall
Product colour	White
Reset button	Yes
LED indicators	Yes

Antenna

Specification	Value
Antenna type	Internal

Weight & dimensions

Specification	Value
Width	160 mm
Depth	160 mm
Height	33.6 mm

Packaging data

Specification	Value
Package type	Box

Packaging content

Specification	Value
Quantity per pack	5 pc(s)
Mounting kit	Yes
Quick start guide	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
