EAP623-Outdoor HD

Model EAP623-Outdoor HDPart no. EAP623-OUTDOOR HDEAN 4895252506303

52 specifications

Speed1800 Mbit/s
ColourWhite
2.4 GHzYes
Security algorithmsSNMP, SNMPv2, SNMPv3, SSH
Ethernet LAN (RJ-45) ports1
PlacementPole

See all specifications

Overview

Speed: 1800 Mbit/s
Colour: White
2.4 GHz: Yes
Security algorithms: SNMP, SNMPv2, SNMPv3, SSH
Ethernet LAN (RJ-45) ports: 1
Placement: Pole

Brand: TP-Link
Category: Wireless Access Point
Model: EAP623-Outdoor HD
Part number: EAP623-OUTDOOR HD
EAN / UPC: 4895252506303, 4895252506310
Also known as: TP-Link Omada AX1800 Indoor/Outdoor Wi-Fi 6 Access Point

Specifications

52 specifications in 11 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
6 GHz	No
Maximum data transfer rate	1800 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Maximum data transfer rate (5 GHz)	1201 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Frequency band	2.4 - 5 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Cabling technology	10/100/1000Base-T(X)
Number of users	1020 user(s)
Automatic channel scanning	Yes
Automatic channel selection	Yes
MIMO	Yes
MIMO type	Multi User MIMO
VLAN support	Yes
Rate limiting	Yes
Band steering	Yes
Airtime Fairness (ATF)	Yes
Quality of Service (QoS) support	Yes
BeamForming	Yes
Transmitting power (CE)	< 20 dBm (2.4 GHz, EIRP), < 30 dBm (5 GHz, EIRP);
Transmitting power (FCC)	< 25 dBm (2.4 GHz), < 25 dBm (5 GHz)

Security

Specification	Value
Security algorithms	SNMP, SNMPv2, SNMPv3, SSH
MAC address filtering	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes
Access Control List (ACL)	Yes

Management features

Specification	Value
Web-based management	Yes
Syslog	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0

Power

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) type supported	Passive PoE

Design

Specification	Value
Placement	Pole
Product colour	White
Reset button	Yes
LED indicators	Yes

Antenna

Specification	Value
Antenna type	Internal
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Antennas quantity	2

Certificates

Specification	Value
Certification	CE, FCC, RoHS

Weight & dimensions

Specification	Value
Width	280.4 mm
Depth	106.5 mm
Height	56.8 mm

Packaging content

Specification	Value
Quantity per pack	1 pc(s)
Mounting kit	Yes
Quick start guide	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-30 - 70 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
