Omada AX1800 Ceiling Mount WiFi 6 Access Point

Model EAP613EAN 840030704307

55 specifications

Speed1775 Mbit/s
ColourWhite
2.4 GHzYes
Number of SSID supported16
Ethernet LAN (RJ-45) ports1
PlacementCeiling, Wall

See all specifications

Overview

Speed: 1775 Mbit/s
Colour: White
2.4 GHz: Yes
Number of SSID supported: 16
Ethernet LAN (RJ-45) ports: 1
Placement: Ceiling, Wall

Brand: TP-Link
Category: Wireless Access Point
Model: EAP613
Part number: EAP613
EAN / UPC: 840030704307, 4895252500516
Also known as: TP-Link Omada AX1800 Ceiling Mount WiFi 6 Access Point

Specifications

55 specifications in 12 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
6 GHz	No
Maximum data transfer rate	1775 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Maximum data transfer rate (5 GHz)	1201 Mbit/s
Ethernet LAN data rates	100,1000 Mbit/s
Frequency band	2.4 - 5 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Automatic channel scanning	Yes
Automatic channel selection	Yes
MIMO	Yes
MIMO type	Multi User MIMO
Spread spectrum method	OFDMA
Wi-Fi Multimedia (WMM)/(WME)	Yes
VLAN support	Yes
Rate limiting	Yes
Wireless isolation	Yes
Band steering	Yes
Airtime Fairness (ATF)	Yes
BeamForming	Yes
Transmitting power (CE)	<20 dBm(2.4 GHz, EIRP); <23 dBm(5 GHz band1/2, EIRP); <25 dBm (5 GHz band3)
Transmitting power (FCC)	<25 dBm (2.4 GHz); <25 dBm (5 GHz)

Security

Specification	Value
Security algorithms	HTTPS, SNMP, SNMPv2, SNMPv3, WPA, WPA2, WPA3
Number of SSID supported	16

Management features

Specification	Value
Web-based management	Yes
Management platform	Omada

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0
DC-in jack	Yes

Power

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) type supported	Passive PoE
DC voltage range	12 V
Input current	1 A
Power consumption (typical)	9.6 W
Power consumption (max)	10.6 W

Design

Specification	Value
Placement	Ceiling, Wall
Product colour	White
Reset button	Yes
LED indicators	Yes

Antenna

Specification	Value
Antenna type	Internal
Antennas quantity	4
Antenna gain level (max)	5 dBi

Performance

Specification	Value
Compatible operating systems	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux

Certificates

Specification	Value
Certification	CE, FCC, RoHS

Weight & dimensions

Specification	Value
Width	160 mm
Depth	160 mm
Height	33.6 mm

Packaging content

Specification	Value
Quantity per pack	1 pc(s)
Mounting kit	Yes
Quick start guide	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	0 - 40%
Operating temperature (T-T)	10 - 90 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%

Omada AX1800 Ceiling Mount WiFi 6 Access Point

Overview

Specifications

Features

Security

Management features

Ports & interfaces

Power

Design

Antenna

Performance

Certificates

Weight & dimensions

Packaging content

Operational conditions
