TP-Link EAP223 V1: Full Specifications

Overview

Speed: 867 Mbit/s
Colour: White
2.4 GHz: Yes
Security algorithms: SSID
Ethernet LAN (RJ-45) ports: 1
Placement: Ceiling, Wall

Brand: TP-Link
Category: Wireless Access Point
Model: EAP223 V1
Part number: EAP223
EAN / UPC: 840030704277, 4895252500509
Also known as: TP-Link AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point

Specifications

50 specifications in 12 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
6 GHz	No
Maximum data transfer rate	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	450 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Automatic channel scanning	Yes
Automatic channel selection	Yes
MIMO	Yes
MIMO type	Multi User MIMO
Wi-Fi Multimedia (WMM)/(WME)	Yes
VLAN support	Yes
Rate limiting	Yes
Wireless isolation	Yes
Band steering	Yes
Quality of Service (QoS) support	Yes
Transmitting power (CE)	20, 23 dBm
Transmitting power (FCC)	24, 22 dBm

Security

Specification	Value
Security algorithms	SSID
MAC address filtering	Yes
Number of SSID supported	15

Management features

Specification	Value
Web-based management	Yes
Syslog	Yes
Management platform	Omada

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1

Power

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) type supported	Active PoE, Passive PoE
Output voltage	48 V
Power consumption (typical)	9.7 W

Design

Specification	Value
Placement	Ceiling, Wall
Product colour	White
Reset button	Yes
LED indicators	Power

Antenna

Specification	Value
Antenna type	Internal
Antenna direction type	Omni-directional
Antennas quantity	3

Performance

Specification	Value
Compatible operating systems	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux

Certificates

Specification	Value
Certification	CE, FCC, RoHS

Weight & dimensions

Specification	Value
Width	205.5 mm
Depth	181.5 mm
Height	37.1 mm

Packaging content

Specification	Value
Quantity per pack	1 pc(s)
Cables included	AC
Mounting kit	Yes
Quick start guide	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
