TP-Link 2.4GHz 300Mbps 9dBi Outdoor CPE

2.4GHz 300Mbps 9dBi Outdoor CPE

Model CPE210Part no. CPE210 V3.20EAN 8459730716774

57 specifications

ProcessorQualcomm Atheros
Memory64 MB
Speed300 Mbit/s
ColourWhite
2.4 GHzYes
Management protocolsTDMA

See all specifications

Overview

Processor: Qualcomm Atheros
Memory: 64 MB
Speed: 300 Mbit/s
Colour: White
2.4 GHz: Yes
Management protocols: TDMA

Brand: TP-Link
Category: Wireless Access Point
Model: CPE210
Part numbers: CPE210 V3.20, CPE210 V1
EAN / UPC: 8459730716774, 845973071677, 6935364071684, 6935364071677
Also known as: TP-Link 2.4GHz 300Mbps 9dBi Outdoor CPE

Specifications

57 specifications in 16 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	No
6 GHz	No
Maximum data transfer rate	300 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Wi-Fi data rate (max)	300 Mbit/s
Frequency band	2.4 - 2.483 GHz
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
MIMO	Yes
VLAN support	Yes
Virtual LAN features	Tagged VLAN
Maximum outdoor range	5000 m
Receiver sensitivity	802.11b: 11M: -95dBm, 5.5M: -96dBm, 2M: -96dBm, 1M: -96dBm -802.11g: 54M: -79dBm, 48M: -80dBm, 36M: -84dBm, 6-24M: -88dBm 802.11n: MCS15: -76dBm, MCS14: -78dBm, MCS13: -80dBm, MCS12: -84dBm, MCS11: -87dBm, MCS10: -91dBm, MCS9: -93dBm, MCS8: -96dBm, MCS7: -76dBm, MCS6: -78dBm, MCS5: -80dBm, MCS4: -84

Security

Specification	Value
Security algorithms	SSID, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
MAC address filtering	Yes
IGMP snooping	Yes

Protocols

Specification	Value
Management protocols	TDMA

Management features

Specification	Value
Web-based management	Yes
Management platform	Pharos Control

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0
WAN connection	Ethernet (RJ-45)

Power

Specification	Value
Power over Ethernet (PoE)	Yes
DC voltage range	16 - 27 V
Power consumption (max)	10.5 W

Design

Specification	Value
Placement	Wall
Product colour	White
International Protection (IP) code	IPX5
Reset button	Yes
LED indicators	Yes
Internal	No

Antenna

Specification	Value
Antenna type	Internal
Antenna features	Integrated antenna
Antennas quantity	1
Antenna gain level (max)	9 dBi

Performance

Specification	Value
Built-in processor	Yes
Processor model	Qualcomm Atheros
Processor frequency	560 MHz
Flash memory	8 MB
Internal memory	64 MB
Compatible operating systems	Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.

Certificates

Specification	Value
Certification	- FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark - RoHS, IPX5

Weight & dimensions

Specification	Value
Width	224.4 mm
Depth	79 mm
Height	60.3 mm

Packaging data

Specification	Value
Package width	270 mm
Package depth	132 mm
Package height	106 mm

Packaging content

Specification	Value
Cables included	AC
Mounting kit	Yes

Other features

Specification	Value
Transmit power range	0 - 27 dBmW

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-30 - 70 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 95%

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
