TP-Link 5 X EAP245 + 1 X OC200

TP-Link 5 X EAP245 + 1 X OC200

Model 5 X EAP245 + 1 X OC200Part no. EAP245-KIT-OC200

60 specifications
  • Speed1750 Mbit/s
  • ColourGrey, White
  • 2.4 GHzYes
  • Ethernet LAN (RJ-45) ports2
  • PlacementCeiling, Wall
  • Antenna typeInternal
See all specifications

Overview

Speed
1750 Mbit/s
Colour
Grey, White
2.4 GHz
Yes
Ethernet LAN (RJ-45) ports
2
Placement
Ceiling, Wall
Antenna type
Internal
Brand
TP-Link
Model
5 X EAP245 + 1 X OC200
Part number
EAP245-KIT-OC200
Also known as
TP-Link 5 X EAP245 + 1 X OC200 1750 Mbit/s Grey, White Power over Ethernet (PoE)

Specifications

60 specifications in 13 groups

Features

2.4 GHzYes
5 GHzYes
Maximum data transfer rate1750 Mbit/s
Maximum data transfer rate (2.4 GHz)450 Mbit/s
Maximum data transfer rate (5 GHz)1300 Mbit/s
Ethernet LAN data rates10,100,1000 Mbit/s
Frequency band2.4, 5 GHz
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af
Cabling technology10/100/1000Base-T(X)
Automatic channel scanningYes
Automatic channel selectionYes
MIMOYes
MIMO typeMulti User MIMO
Wi-Fi Multimedia (WMM)/(WME)Yes
Wi-Fi roamingYes
VLAN supportYes
Virtual LAN featuresSSID-based VLAN assignment
Rate limitingYes
Wireless isolationYes
Band steeringYes
Airtime Fairness (ATF)Yes
Quality of Service (QoS) supportYes
Transmitting power27 dBmW

Security

Security algorithms64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
MAC address filteringYes
Number of SSID supported16

Management features

Web-based managementYes
SyslogYes

Ports & interfaces

Ethernet LAN (RJ-45) ports2
USB 2.0 ports quantity0
DC-in jackYes

Power

Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) type supportedActive PoE, Passive PoE
AC input voltage48 V
Input current1.5 A
Power consumption (typical)12.3 W

Design

PlacementCeiling, Wall
Product colourGrey, White
Cable lock slotYes
Reset buttonYes
LED indicatorsYes

Antenna

Antenna typeInternal
Antenna direction typeOmni-directional
Antenna featuresIntegrated antenna
Antenna gain level (max)4 dBi

Performance

Compatible operating systemsMicrosoft Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10

Certificates

CertificationCE, FCC, RoHS

Weight & dimensions

Width206 mm
Depth182 mm
Height37 mm

Packaging data

Package typeBox

Packaging content

Quantity per pack6 pc(s)
PoE adapter includedYes
Cables includedAC
Mounting kitYes
Quick start guideYes

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)5 - 90%
