TP-Link 2.4GHz 300Mbps 9dBi Outdoor CPE

2.4GHz 300Mbps 9dBi Outdoor CPE

Model 2.4GHz 300Mbps 9dBi Outdoor CPEPart no. CPE210EAN 6935364082253

51 specifications

ProcessorQualcomm Atheros
Memory64 MB
Speed300 Mbit/s
ColourWhite
2.4 GHzYes
Management protocolsTDMA

See all specifications

Overview

Processor: Qualcomm Atheros
Memory: 64 MB
Speed: 300 Mbit/s
Colour: White
2.4 GHz: Yes
Management protocols: TDMA

Brand: TP-Link
Category: Wireless Access Point
Model: 2.4GHz 300Mbps 9dBi Outdoor CPE
Part number: CPE210
EAN / UPC: 6935364082253, 638347504464, 731215288029, 758399148697 +9 more
Also known as: TP-Link 2.4GHz 300Mbps 9dBi Outdoor CPE 300 Mbit/s White Power over Ethernet (PoE)

Specifications

51 specifications in 14 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	No
Maximum data transfer rate	300 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Frequency band	2.4 - 2.483 GHz
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
MIMO	Yes
MIMO type	Multi User MIMO
Maximum outdoor range	5000 m
Receiver sensitivity	802.11b: 11M: -95dBm, 5.5M: -96dBm, 2M: -96dBm, 1M: -96dBm -802.11g: 54M: -79dBm, 48M: -80dBm, 36M: -84dBm, 6-24M: -88dBm 802.11n: MCS15: -76dBm, MCS14: -78dBm, MCS13: -80dBm, MCS12: -84dBm, MCS11: -87dBm, MCS10: -91dBm, MCS9: -93dBm, MCS8: -96dBm, MCS7: -76dBm, MCS6: -78dBm, MCS5: -80dBm, MCS4: -84

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, SSID, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
MAC address filtering	Yes

Protocols

Specification	Value
Management protocols	TDMA

Management features

Specification	Value
Web-based management	Yes
Management platform	Pharos Control

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0

Power

Specification	Value
Power over Ethernet (PoE)	Yes
AC input frequency	50 - 60 Hz
AC input voltage	100 - 240 V
Input current	0.8 A
Output voltage	24 V
Output current	1 A
Power consumption (max)	10.5 W

Design

Specification	Value
Placement	Wall
Product colour	White
International Protection (IP) code	IPX5
Reset button	Yes
LED indicators	Yes

Antenna

Specification	Value
Antenna type	Internal
Antenna features	Integrated antenna
Antennas quantity	1
Antenna gain level (max)	9 dBi

Performance

Specification	Value
Built-in processor	Yes
Processor model	Qualcomm Atheros
Processor frequency	560 MHz
Flash memory	8 MB
Internal memory	64 MB
Compatible operating systems	Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.

Certificates

Specification	Value
Certification	- FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark - RoHS, IPX5

Weight & dimensions

Specification	Value
Width	224 mm
Depth	79 mm
Height	60 mm

Packaging content

Specification	Value
Cables included	AC
Mounting kit	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-30 - 70 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 95%

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
