CPE Point-to-Point 900Mbps at
5.8GHz 12dBi
Model I-WL-CPE200EAN 8059018361711
41 specifications
- Speed900 Mbit/s
- Weight545 g
- ColourWhite
- 2.4 GHzYes
- Management protocolsHTTP, Telnet
- Ethernet LAN (RJ-45) ports1
Overview
- Speed
- 900 Mbit/s
- Weight
- 545 g
- Colour
- White
- 2.4 GHz
- Yes
- Management protocols
- HTTP, Telnet
- Ethernet LAN (RJ-45) ports
- 1
- Brand
- Techly
- Category
- Wireless Access Point
- Model
- I-WL-CPE200
- Part number
- I-WL-CPE200
- EAN / UPC
- 8059018361711
- Also known as
- Techly CPE Point-to-Point 900Mbps at 5.8GHz 12dBi
Specifications
41 specifications in 13 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | No |
| Maximum data transfer rate | 900 Mbit/s |
| Frequency band | 5.8 GHz |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| MIMO | Yes |
| Operating modes | AP / Repeater |
| Receiver sensitivity | MCS7: -68dbm / MCS0: -86dbm |
Protocols
| Specification | Value |
|---|---|
| Management protocols | HTTP, Telnet |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Syslog | Yes |
| Firmware upgradeable | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 0 |
| WAN connection | Ethernet (RJ-45) |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | Passive PoE |
Design
| Specification | Value |
|---|---|
| Placement | Wall |
| Product colour | White |
| Reset button | Yes |
| LED indicators | LAN, Power, WAN, Wi-Fi |
Antenna
| Specification | Value |
|---|---|
| Antenna type | Internal |
| Antenna features | Integrated antenna |
| Antenna gain level (max) | 12 dBi |
| Polarization | Dual polarization |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, WEEE |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 88 mm |
| Depth | 47.6 mm |
| Height | 168 mm |
| Weight | 545 g |
Packaging content
| Specification | Value |
|---|---|
| PoE adapter included | Yes |
| Cables included | LAN (RJ-45) |
| Quick start guide | Yes |
Other features
| Specification | Value |
|---|---|
| Horizontal beam width | 60° |
| Vertical beam width | 33° |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -30 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
