SIL-WCAP-AX-W 1800 Mbit/s White Power over Ethernet (PoE)
Model SIL-WCAP-AX-WPart no. SIL WCAP-AX-WEAN 5060693982545
48 specifications
- Memory128 MB
- Speed1800 Mbit/s
- Weight140 g
- ColourWhite
- 2.4 GHzYes
- Ethernet LAN (RJ-45) ports0
Overview
- Memory
- 128 MB
- Speed
- 1800 Mbit/s
- Weight
- 140 g
- Colour
- White
- 2.4 GHz
- Yes
- Ethernet LAN (RJ-45) ports
- 0
- Brand
- SilverNet
- Category
- Wireless Access Point
- Model
- SIL-WCAP-AX-W
- Part number
- SIL WCAP-AX-W
- EAN / UPC
- 5060693982545
- Also known as
- SilverNet SIL-WCAP-AX-W 1800 Mbit/s White Power over Ethernet (PoE)
Specifications
48 specifications in 13 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 1800 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3af |
| Number of users | 100 user(s) |
| MIMO | Yes |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Maximum outdoor range | 50 m |
| Transmitting power | 17 dBmW |
Security
| Specification | Value |
|---|---|
| Security algorithms | WEP, WPA, WPA-AES, WPA-Enterprise, WPA-PSK, WPA-TKIP, WPA2, WPA2-AES, WPA2-TKIP |
| MAC address filtering | Yes |
| Service Set Identifier (SSID) features | Multiple SSIDs |
| Number of SSID supported | 8 |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 0 |
| USB 2.0 ports quantity | 0 |
| USB connector type | USB Type-C |
| WAN connection | Ethernet (RJ-45) |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Output voltage | 48 V |
| Output current | 0.32 A |
| Power consumption (max) | 6 W |
Design
| Specification | Value |
|---|---|
| Placement | Wall |
| Product colour | White |
| Reset button | Yes |
Antenna
| Specification | Value |
|---|---|
| Antenna type | Internal |
| Antenna direction type | Omni-directional |
| Antenna gain level (max) | 2 dBi |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | MediaTek |
| Flash memory | 16 MB |
| Internal memory | 128 MB |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 86 mm |
| Depth | 86 mm |
| Height | 10.5 mm |
| Weight | 140 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 108 mm |
| Package depth | 109 mm |
| Package height | 63 mm |
| Package weight | 240 g |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -20 - 40 °C |
Logistics data
| Specification | Value |
|---|---|
| UK Trade Tariff code | 85176200 |
| Warranty period | 1 year(s) |
