WEA512i 866 Mbit/s White Power over Ethernet (PoE)
Model WEA512iPart no. WDS-A512I
36 specifications
- Speed866 Mbit/s
- Weight270 g
- ColourWhite
- 2.4 GHzYes
- Number of SSID supported16
- Ethernet LAN (RJ-45) ports1
Overview
- Speed
- 866 Mbit/s
- Weight
- 270 g
- Colour
- White
- 2.4 GHz
- Yes
- Number of SSID supported
- 16
- Ethernet LAN (RJ-45) ports
- 1
- Brand
- Samsung
- Category
- Wireless Access Point
- Model
- WEA512i
- Part number
- WDS-A512I
- Also known as
- Samsung WEA512i 866 Mbit/s White Power over Ethernet (PoE)
Specifications
36 specifications in 10 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 866 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Frequency band | 2.412-2.472; 5.18-5.825 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Modulation | 256-QAM |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Wi-Fi Multimedia (WMM) features | WMM power saving |
| Wi-Fi roaming | Yes |
| Dynamic Frequency Selection (DFS) | Yes |
| Quality of Service (QoS) support | Yes |
| Transmitting power | 22 dBmW |
Security
| Specification | Value |
|---|---|
| Security algorithms | EAP, EAP-AKA, EAP-FAST, EAP-SIM, EAP-TLS, EAP-TTLS, PEAP, TKIP, WPA, WPA2 |
| Number of SSID supported | 16 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Output voltage | 48 V |
| Output current | 0.27 A |
| Power supply | 10 W |
Design
| Specification | Value |
|---|---|
| Placement | Wall |
| Product colour | White |
Antenna
| Specification | Value |
|---|---|
| Antenna type | Internal |
| Antenna gain level (max) | 6 dBi |
Certificates
| Specification | Value |
|---|---|
| Certification | EN 60950-1 KN 301 489-1/KN 301 489-17 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 167.3 mm |
| Depth | 167.3 mm |
| Height | 34.1 mm |
| Weight | 270 g |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -25 - 70 °C |
