WEA463e 1300 Mbit/s Grey Power over Ethernet (PoE)
Model WEA463ePart no. WDS-A463E
34 specifications
- Speed1300 Mbit/s
- Weight2.8 kg
- ColourGrey
- 2.4 GHzYes
- Ethernet LAN (RJ-45) ports2
- PlacementWall
Overview
- Speed
- 1300 Mbit/s
- Weight
- 2.8 kg
- Colour
- Grey
- 2.4 GHz
- Yes
- Ethernet LAN (RJ-45) ports
- 2
- Placement
- Wall
- Brand
- Samsung
- Category
- Wireless Access Point
- Model
- WEA463e
- Part number
- WDS-A463E
- Also known as
- Samsung WEA463e 1300 Mbit/s Grey Power over Ethernet (PoE)
Specifications
34 specifications in 10 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 1300 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Frequency band | 2.412-2.472; 5.18-5.825 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at |
| Channel bandwidth | 80 MHz |
| MIMO | Yes |
| Modulation | DSSS, OFDM |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Wi-Fi Multimedia (WMM) features | WMM power saving |
| Quality of Service (QoS) support | Yes |
| Transmitting power | 29 dBmW |
Security
| Specification | Value |
|---|---|
| Security algorithms | EAP-AKA, EAP-FAST, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA, WPA2 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 0 |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power supply | 25.5 W |
Design
| Specification | Value |
|---|---|
| Placement | Wall |
| Product colour | Grey |
| International Protection (IP) code | IP67 |
| LED indicators | Status |
Antenna
| Specification | Value |
|---|---|
| Antenna type | Internal |
| Antenna connector type | RF |
| Number of connectors | 6 |
Certificates
| Specification | Value |
|---|---|
| Certification | IEC 60950-1 EN 60950-1 UL 60950-1 CAN/CSA-C22.2 No. 60950-1 FCC 15.247, 15.407 FCC 15.107 and 15.109 RSS-210 ICES-003 EN 300 328, EN 301 893 EN 301 489-1 and -17 KN 301 489-1/KN 301 489-17 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 267 mm |
| Depth | 184 mm |
| Height | 57.5 mm |
| Weight | 2.8 kg |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 5 - 100% |
| Operating temperature (T-T) | -40 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
