NETGEAR WiFi 6 AX1800 Dual Band Access Point (WAX202)

WiFi 6 AX1800 Dual Band Access Point (WAX202)

Model WiFi 6 AX1800 Dual Band Access Point (WAX202)Part no. WAX202-100EUSEAN 606449154894

41 specifications

Speed1800 Mbit/s
Weight497 g
ColourWhite
2.4 GHzYes
Security algorithmsSSID, WPA, WPA2, WPA3
Ethernet LAN (RJ-45) ports3

See all specifications

Overview

Speed: 1800 Mbit/s
Weight: 497 g
Colour: White
2.4 GHz: Yes
Security algorithms: SSID, WPA, WPA2, WPA3
Ethernet LAN (RJ-45) ports: 3

Brand: NETGEAR
Category: Wireless Access Point
Model: WiFi 6 AX1800 Dual Band Access Point (WAX202)
Part numbers: WAX202-100EUS, WAX202-100AUS
EAN / UPC: 606449154894, 10606449154891
Also known as: NETGEAR WiFi 6 AX1800 Dual Band Access Point (WAX202) 1800 Mbit/s White

Specifications

41 specifications in 12 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	1800 Mbit/s
Maximum data transfer rate (2.4 GHz)	600 Mbit/s
Maximum data transfer rate (5 GHz)	1200 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Number of users	128 user(s)

Security

Specification	Value
Security algorithms	SSID, WPA, WPA2, WPA3
MAC address filtering	Yes
Number of SSID supported	3
Access Control List (ACL)	Yes

Management features

Specification	Value
Web-based management	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	3
USB 2.0 ports quantity	0
WAN connection	Ethernet (RJ-45)
DC-in jack	Yes

Power

Specification	Value
Power over Ethernet (PoE)	No
AC input voltage	12 V
Input current	1.5 A
Power supply	18 W

Design

Specification	Value
Placement	Table
Product colour	White
Reset button	Yes
LED indicators	Yes

Antenna

Specification	Value
Antenna type	Internal
Antennas quantity	2
Antenna gain level (max)	3.5 dBi

Certificates

Specification	Value
Certification	CB IEC60950-1, CE LVD EN62368-1

Weight & dimensions

Specification	Value
Width	170 mm
Depth	242 mm
Height	63 mm
Weight	497 g

Packaging content

Specification	Value
Quantity per pack	1 pc(s)
AC adapter included	Yes
Cables included	LAN (RJ-45)

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 95%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 95%

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
