LevelOne AC750 Dual Band PoE Wireless Access Point, In-Wall Mount, Controller Managed

LevelOne AC750 Dual Band PoE Wireless Access Point, In-Wall Mount, Controller Managed

Model WAP-8221EAN 4015867206539

56 specifications

Speed750 Mbit/s
Weight104 g
ColourWhite
2.4 GHzYes
Service Set Identifier (SSID) featuresSSID broadcast on/off
Ethernet LAN (RJ-45) ports1

See all specifications

Overview

Speed: 750 Mbit/s
Weight: 104 g
Colour: White
2.4 GHz: Yes
Service Set Identifier (SSID) features: SSID broadcast on/off
Ethernet LAN (RJ-45) ports: 1

Brand: LevelOne
Category: Wireless Access Point
Model: WAP-8221
Part number: WAP-8221
EAN / UPC: 4015867206539
Also known as: LevelOne AC750 Dual Band PoE Wireless Access Point, In-Wall Mount, Controller Managed

Specifications

56 specifications in 13 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	750 Mbit/s
Wi-Fi data rate (max)	433 Mbit/s
Ethernet LAN data rates	10,100 Mbit/s
Frequency band	2.4 ~ 2.483, 5.180 ~ 5.825 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
Number of users	128 user(s)
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK
Wi-Fi Multimedia (WMM)/(WME)	Yes
Operating modes	Access Point (AP),Gateway,Repeater,WISP
Flow control support	Yes
Quality of Service (QoS) support	Yes

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, AES, TKIP, WPA, WPA-PSK, WPA2
Service Set Identifier (SSID) features	SSID broadcast on/off
Number of SSID supported	8

Management features

Specification	Value
Web-based management	Yes
Switch type	Managed
Firmware upgradeable	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
WAN connection	Ethernet (RJ-45)

Power

Specification	Value
Power over Ethernet (PoE)	Yes
Power consumption (typical)	10 W

Design

Specification	Value
Placement	Wall
Product colour	White
Reset button	Yes
LED indicators	Power, Status
Internal	No

Antenna

Specification	Value
Antenna features	Integrated antenna
Antennas quantity	3
Antenna gain level (max)	2 dBi

Certificates

Specification	Value
Certification	CE

Weight & dimensions

Specification	Value
Width	86 mm
Depth	31 mm
Height	86 mm
Weight	104 g

Packaging data

Specification	Value
CD manual	Yes
CD quick installation guide	Yes
Package width	110 mm
Package depth	65 mm
Package height	120 mm
Package weight	202 g
Package type	Box

Packaging content

Specification	Value
Mounting kit	Yes
Quick start guide	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-20 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 95%

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
Country of origin	China
Master (outer) case width	340 mm
Master (outer) case length	580 mm
Master (outer) case height	515 mm
Master (outer) case gross weight	21.3 kg
Products per master (outer) case	100 pc(s)
