LevelOne AC750 Dual Band PoE Wireless Access Point, Ceiling Mount, Controller Managed

LevelOne AC750 Dual Band PoE Wireless Access Point, Ceiling Mount, Controller Managed

Model WAP-8121EAN 401586719919

53 specifications

Speed433 Mbit/s
Weight326 g
ColourWhite
2.4 GHzYes
Service Set Identifier (SSID) featuresSSID broadcast on/off
Ethernet LAN (RJ-45) ports2

See all specifications

Overview

Speed: 433 Mbit/s
Weight: 326 g
Colour: White
2.4 GHz: Yes
Service Set Identifier (SSID) features: SSID broadcast on/off
Ethernet LAN (RJ-45) ports: 2

Brand: LevelOne
Category: Wireless Access Point
Model: WAP-8121
Part number: WAP-8121
EAN / UPC: 401586719919, 4015867199190
Also known as: LevelOne AC750 Dual Band PoE Wireless Access Point, Ceiling Mount, Controller Managed

Specifications

53 specifications in 13 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	433 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Frequency band	2.4 - 5.825 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
Number of users	80 user(s)
Channels quantity	36 channels
Automatic channel selection	Yes
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK
Wi-Fi Multimedia (WMM)/(WME)	Yes
Flow control support	Yes
Quality of Service (QoS) support	Yes
Receiver sensitivity	2.4GHz: 802.11n (20MHZ): -70 dBm 802.11n (40MHZ): -68 dBm 802.11g: -72 dBm 802.11b: -95 dBm 5GHz: 802.11ac (80MHZ): -62 dBm 802.11ac (40MHZ): -65 dBm 802.11ac (20MHZ): -68 dBm 802.11n (40MHZ): -68 dBm 802.11n (20MHZ): -70 dBm 802.11a: -72 dBm

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP
Service Set Identifier (SSID) features	SSID broadcast on/off
Number of SSID supported	8

Management features

Specification	Value
Web-based management	Yes
Switch type	Managed
Firmware upgradeable	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	0
WAN connection	Ethernet (RJ-45), Wi-Fi
DC-in jack	Yes

Power

Specification	Value
Power over Ethernet (PoE)	Yes
Output voltage	12 V
Output current	1.5 A
Power consumption (typical)	15 W

Design

Specification	Value
Placement	Ceiling, Wall
Product colour	White
Reset button	Yes
LED indicators	Power, WLAN
Internal	No

Antenna

Specification	Value
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Antennas quantity	3
Antenna gain level (max)	15 dBi

Certificates

Specification	Value
Certification	CE/FCC

Weight & dimensions

Specification	Value
Width	189 mm
Depth	38.5 mm
Height	189 mm
Weight	326 g

Packaging data

Specification	Value
Package width	214 mm
Package depth	62 mm
Package height	317 mm
Package weight	680 g

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
Quick start guide	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	-20 - 50%
Operating temperature (T-T)	-40 - 70 °C
Storage temperature (T-T)	5 - 90 °C
Storage relative humidity (H-H)	10 - 90%

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
