LevelOne Managed Ceiling Mount Gigabit Wireless Access Point, 1200Mbps 802.11a/b/g/n/ac, 802.3af PoE, Built-in Antenna, Dual-Band

LevelOne Managed Ceiling Mount Gigabit Wireless Access Point, 1200Mbps 802.11a/b/g/n/ac, 802.3af PoE, Built-in Antenna, Dual-Band

Model WAP-8101EAN 4015867191422

39 specifications
  • Speed1200 Mbit/s
  • Weight300 g
  • ColourWhite
  • 2.4 GHzYes
  • Ethernet LAN (RJ-45) ports1
  • PlacementCeiling
See all specifications

Overview

Speed
1200 Mbit/s
Weight
300 g
Colour
White
2.4 GHz
Yes
Ethernet LAN (RJ-45) ports
1
Placement
Ceiling
Brand
LevelOne
Model
WAP-8101
Part number
WAP-8101
EAN / UPC
4015867191422
Also known as
LevelOne Managed Ceiling Mount Gigabit Wireless Access Point, 1200Mbps 802.11a/b/g/n/ac, 802.3af PoE, Built-in Antenna, Dual-Band

Specifications

39 specifications in 11 groups

Features

2.4 GHzYes
5 GHzYes
Maximum data transfer rate1200 Mbit/s
Ethernet LAN data rates10,100,1000 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
Number of users128 user(s)
Channels quantity13 channels
Quality of Service (QoS) supportYes

Security

Security algorithms64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA2-AES, WPA2-PSK, WPA2-TKIP

Management features

Web-based managementYes
Firmware upgradeableYes

Ports & interfaces

Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity0
DC-in jackYes

Power

Power over Ethernet (PoE)Yes
AC input voltage12 V
Input current1 A

Design

PlacementCeiling
Product colourWhite
Reset buttonYes
LED indicatorsPoE, Status, WLAN
InternalNo

Antenna

Antenna featuresIntegrated antenna
Antennas quantity2
Antenna gain level (max)5 dBi

Weight & dimensions

Width150 mm
Depth150 mm
Height57.5 mm
Weight300 g

Packaging data

Package width275 mm
Package depth220 mm
Package height65 mm

Packaging content

AC adapter includedYes
Cables includedLAN (RJ-45)
Quick start guideYes

Operational conditions

Operating relative humidity (H-H)0 - 40%
Operating temperature (T-T)-40 - 85 °C
Storage temperature (T-T)10 - 90 °C
Storage relative humidity (H-H)0 - 95%
