LevelOne WAP-6012 wireless access point 1000 Mbit/s

WAP-6012 wireless access point 1000 Mbit/s

Model WAP-6012EAN 4015867158067

29 specifications

Speed1000 Mbit/s
Weight320 g
MAC address filteringYes
Ethernet LAN (RJ-45) ports1
Power requirements12 V
Antenna typeExternal

See all specifications

Overview

Speed: 1000 Mbit/s
Weight: 320 g
MAC address filtering: Yes
Ethernet LAN (RJ-45) ports: 1
Power requirements: 12 V
Antenna type: External

Brand: LevelOne
Category: Wireless Access Point
Model: WAP-6012
Part number: WAP-6012
EAN / UPC: 4015867158067
Also known as: LevelOne WAP-6012 wireless access point 1000 Mbit/s

Specifications

29 specifications in 11 groups

Features

Specification	Value
Maximum data transfer rate	1000 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Frequency band	2.412 - 2.4835 GHz
Cabling technology	10/100/1000Base-T(X)
Channels quantity	13 channels
Quality of Service (QoS) support	Yes
Receiver sensitivity	11n: 300Mbps@ -69dBm, 11g: 54Mbps@ -73dBm, 11b: 11Mbps@ -88dBm OFDM; 802.11b: CCK(11Mbps, 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps)

Security

Specification	Value
Security algorithms	EAP, WPA, WPA-PSK, WPA2, WPA2-PSK
MAC address filtering	Yes

Protocols

Specification	Value
DHCP client	Yes
Management protocols	SNMP v1/v2/v3, LLTD

Management features

Specification	Value
Web-based management	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes

Power

Specification	Value
Power requirements	12 V
Power supply	12 W
Power supply type	DC

Design

Specification	Value
LED indicators	Yes

Antenna

Specification	Value
Antenna type	External
Antenna features	Detachable antenna
Antennas quantity	3
Antenna gain level (max)	2 dBi

Weight & dimensions

Specification	Value
Dimensions (WxDxH)	165 x 153 x 33 mm
Weight	320 g

Other features

Specification	Value
Supported data transfer rates	1, 2, 5.5, 11, 54
Compliance industry standards	IEEE 802.11u, IEEE 802.11n, IEEE 802.11b, IEEE 802.11g
Wireless technology	Wi-Fi

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C
