LevelOne AC1200 Dual Band Outdoor PoE Wireless Access Point, Controller Managed

LevelOne AC1200 Dual Band Outdoor PoE Wireless Access Point, Controller Managed

Model WAB-8011EAN 4015867200384

54 specifications

Speed1200 Mbit/s
Weight4 kg
ColourGrey
2.4 GHzYes
Service Set Identifier (SSID) featuresSSID broadcast on/off
Ethernet LAN (RJ-45) ports1

See all specifications

Overview

Speed: 1200 Mbit/s
Weight: 4 kg
Colour: Grey
2.4 GHz: Yes
Service Set Identifier (SSID) features: SSID broadcast on/off
Ethernet LAN (RJ-45) ports: 1

Brand: LevelOne
Category: Wireless Access Point
Model: WAB-8011
Part number: WAB-8011
EAN / UPC: 4015867200384
Also known as: LevelOne AC1200 Dual Band Outdoor PoE Wireless Access Point, Controller Managed

Specifications

54 specifications in 13 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	1200 Mbit/s
Wi-Fi data rate (max)	433 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Frequency band	2.4 - 2.483, 5.15 - 5.35, 5.46 - 5.72, 5.725 - 5.82 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Number of users	100 user(s)
Channels quantity	165 channels
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM
Wi-Fi Multimedia (WMM)/(WME)	Yes
Operating modes	Access Point (AP),Gateway,Repeater,WISP
Quality of Service (QoS) support	Yes

Security

Specification	Value
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Service Set Identifier (SSID) features	SSID broadcast on/off
Number of SSID supported	4

Management features

Specification	Value
Web-based management	Yes
Firmware upgradeable	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	0
WAN connection	Ethernet (RJ-45)

Power

Specification	Value
Power over Ethernet (PoE)	Yes
Power consumption (typical)	30 W

Design

Specification	Value
Product colour	Grey
International Protection (IP) code	IP65
Reset button	Yes
Internal	No

Antenna

Specification	Value
Antenna connector type	N-type
Number of connectors	4

Certificates

Specification	Value
Certification	CE, FCC

Weight & dimensions

Specification	Value
Width	230 mm
Depth	380 mm
Height	85 mm
Weight	4 kg

Packaging data

Specification	Value
CD manual	Yes
CD quick installation guide	Yes
Package width	285 mm
Package depth	455 mm
Package height	125 mm
Package weight	4.4 kg
Package type	Box

Packaging content

Specification	Value
Mounting kit	Yes
Quick start guide	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-40 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
Country of origin	China
Master (outer) case width	475 mm
Master (outer) case length	650 mm
Master (outer) case height	305 mm
Master (outer) case gross weight	23.5 kg
Products per master (outer) case	5 pc(s)
