LevelOne Managed Wireless Access Point, Detachable Antenna, 300Mbps 802.11b/g/n, 802.3af PoE

LevelOne Managed Wireless Access Point, Detachable Antenna, 300Mbps 802.11b/g/n, 802.3af PoE

Model EAP-200EAN 4015867165997

49 specifications
  • Speed300 Mbit/s
  • Weight610 g
  • ColourBlack
  • 2.4 GHzYes
  • Ethernet LAN (RJ-45) ports2
  • PlacementWall
See all specifications

Overview

Speed
300 Mbit/s
Weight
610 g
Colour
Black
2.4 GHz
Yes
Ethernet LAN (RJ-45) ports
2
Placement
Wall
Brand
LevelOne
Model
EAP-200
Part number
EAP-200
EAN / UPC
4015867165997
Also known as
LevelOne Managed Wireless Access Point, Detachable Antenna, 300Mbps 802.11b/g/n, 802.3af PoE

Specifications

49 specifications in 12 groups

Features

2.4 GHzYes
5 GHzNo
Maximum data transfer rate300 Mbit/s
Ethernet LAN data rates10,100 Mbit/s
Frequency band2.4 GHz
Networking standardsIEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af
Number of users128 user(s)
Channels quantity14 channels
Spread spectrum methodDSSS
Modulation16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK
VLAN supportYes
Quality of Service (QoS) supportYes

Security

Security algorithms802.1x RADIUS, EAP-TLS, EAP-TTLS, PEAP, SNMP, TKIP, WEP, WPA, WPA2
MAC address filteringYes

Protocols

DHCP serverYes
DHCP clientYes

Management features

Web-based managementYes
Switch typeManaged
Firmware upgradeableYes

Ports & interfaces

Ethernet LAN (RJ-45) ports2
USB 2.0 ports quantity1
DC-in jackYes

Power

Power over Ethernet (PoE)Yes
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Output voltage12 V
Output current1.5 A

Design

PlacementWall
Product colourBlack
Housing materialMetal
International Protection (IP) codeIP50
Reset buttonYes
LED indicatorsLAN, Power, USB, WLAN
InternalNo

Antenna

Antenna featuresDetachable antenna
Antennas quantity2
Antenna gain level (max)5 dBi

Certificates

CertificationFCC, CE, RoHS

Weight & dimensions

Width204 mm
Depth134 mm
Height35 mm
Weight610 g

Packaging content

AC adapter includedYes
Cables includedLAN (RJ-45), RS-232
Quick start guideYes

Operational conditions

Operating relative humidity (H-H)10 - 80%
Operating temperature (T-T)-30 - 70 °C
Storage temperature (T-T)-40 - 85 °C
Storage relative humidity (H-H)5 - 90%
