LevelOne AC750 White Power over Ethernet (PoE)

LevelOne AC750 White Power over Ethernet (PoE)

Model AC750Part no. WAP-8111EAN 4015867196779

46 specifications
  • Weight250 g
  • ColourWhite
  • 2.4 GHzYes
  • Service Set Identifier (SSID) featuresSSID broadcast on/off
  • Ethernet LAN (RJ-45) ports2
  • PlacementCeiling
See all specifications

Overview

Weight
250 g
Colour
White
2.4 GHz
Yes
Service Set Identifier (SSID) features
SSID broadcast on/off
Ethernet LAN (RJ-45) ports
2
Placement
Ceiling
Brand
LevelOne
Model
AC750
Part number
WAP-8111
EAN / UPC
4015867196779
Also known as
LevelOne AC750 White Power over Ethernet (PoE)

Specifications

46 specifications in 11 groups

Features

2.4 GHzYes
5 GHzYes
Wi-Fi data rate (max)433 Mbit/s
Ethernet LAN data rates10,100 Mbit/s
Frequency band5.725 - 5.825 GHz
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Number of users63 user(s)
Channels quantity3 channels
Automatic channel selectionYes
Wi-Fi Multimedia (WMM)/(WME)Yes
Operating modesAccess Point (AP),WDS
Flow control supportYes
Quality of Service (QoS) supportYes

Security

Security algorithmsAES, SSID, TKIP, WEP, WPA, WPA-PSK, WPA2
Service Set Identifier (SSID) featuresSSID broadcast on/off
Number of SSID supported4
Auto Wireless Distribution System (WDS)Yes

Management features

Web-based managementYes
Switch typeManaged
Firmware upgradeableYes

Ports & interfaces

Ethernet LAN (RJ-45) ports2
USB 2.0 ports quantity0
WAN connectionEthernet (RJ-45)
DC-in jackYes

Power

Power over Ethernet (PoE)Yes
Output voltage12 V
Output current1 A

Design

PlacementCeiling
Product colourWhite
Reset buttonYes
LED indicatorsWLAN
InternalNo

Antenna

Antenna featuresIntegrated antenna
Antennas quantity3
Antenna gain level (max)9 dBi

Weight & dimensions

Width200 mm
Depth175 mm
Height41 mm
Weight250 g

Packaging data

CD manualYes
CD quick installation guideYes

Packaging content

Cables includedLAN (RJ-45)

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-10 - 70 °C
Storage relative humidity (H-H)0 - 95%
