EnGenius EWS550AP Managed AP Indoor Wall Plate Dual Band 11ac Wave2, 400+867Mbps 2T2R GbE
2x4dBi (2.4Ghz) + 2x6dBi (5Ghz) antenna 1 x GigE Uplink, 2 x GigE Swi
Model EWS550APEAN 655216008564
35 specifications
- Speed1267 Mbit/s
- Weight454 g
- ColourWhite
- 2.4 GHzYes
- Ethernet LAN (RJ-45) ports2
- PlacementWall
Overview
- Speed
- 1267 Mbit/s
- Weight
- 454 g
- Colour
- White
- 2.4 GHz
- Yes
- Ethernet LAN (RJ-45) ports
- 2
- Placement
- Wall
- Brand
- EnGenius
- Category
- Wireless Access Point
- Model
- EWS550AP
- Part number
- EWS550AP
- EAN / UPC
- 655216008564, 4713361931628
- Also known as
- EnGenius EWS550AP Managed AP Indoor Wall Plate Dual Band 11ac Wave2, 400+867Mbps 2T2R GbE, 2x4dBi (2.4Ghz) + 2x6dBi (5Ghz) antenna 1 x GigE Uplink, 2 x GigE Swi
Specifications
35 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 1267 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 400 Mbit/s |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bandwidth | 5 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n |
| Automatic channel scanning | Yes |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Modulation | 16-QAM, 64-QAM, 256-QAM, BPSK, QPSK |
| Fast roaming | Yes |
| Virtual LAN features | Tagged VLAN |
| Band steering | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | 64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-AES, WPA-EAP, WPA-TKIP, WPA2-Enterprise |
| MAC address filtering | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power consumption (max) | 10 W |
Design
| Specification | Value |
|---|---|
| Placement | Wall |
| Product colour | White |
| Reset button | Yes |
| LED indicators | Yes |
| Internal | No |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 125 mm |
| Depth | 188 mm |
| Height | 26 mm |
| Weight | 454 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Storage relative humidity (H-H) | 0 - 90% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
