EWS385AP Managed AP Indoor Triband AP 11ac Wave2 AC2200 400+867+867 2T2R

2 x 5dBi + 4 x 6dBi ia 2GbE PoE.af

Model EWS385APEAN 655216009509

56 specifications

Speed1734 Mbit/s
Weight40.64 g
ColourWhite
2.4 GHzYes
Management protocolsSNMP
Ethernet LAN (RJ-45) ports2

See all specifications

Overview

Speed: 1734 Mbit/s
Weight: 40.64 g
Colour: White
2.4 GHz: Yes
Management protocols: SNMP
Ethernet LAN (RJ-45) ports: 2

Brand: EnGenius
Category: Wireless Access Point
Model: EWS385AP
Part number: EWS385AP
EAN / UPC: 655216009509, 4713361934698
Also known as: EnGenius EWS385AP Managed AP Indoor Triband AP 11ac Wave2 AC2200 400+867+867 2T2R 2 x 5dBi + 4 x 6dBi ia 2GbE PoE.af

Specifications

56 specifications in 13 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	1734 Mbit/s
Maximum data transfer rate (2.4 GHz)	400 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Frequency band	2.412 - 2.484, 5.18-5.24 & 5.26-5.32 & 5.5-5.7 & 5.745-5.825, 5.15-5.25, 5.25-5.35
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Automatic channel selection	Yes
MIMO	Yes
MIMO type	Multi User MIMO
Spread spectrum method	DSSS, OFDM
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DQPSK, QPSK
Fit AP mode features	Mesh networking
Wi-Fi Multimedia (WMM)/(WME)	Yes
Fast roaming	Yes
VLAN support	Yes
Virtual LAN features	Tagged VLAN
Band steering	Yes
Quality of Service (QoS) support	Yes

Security

Specification	Value
Security algorithms	802.1x RADIUS, MD5, PEAP, SSL/TLS, TTLS, WPA2-EAP, WPA2-PSK
MAC address filtering	Yes
Service Set Identifier (SSID) features	Multiple SSIDs
Number of SSID supported	8

Protocols

Specification	Value
Management protocols	SNMP

Management features

Specification	Value
Web-based management	Yes
Command-line interface (CLI)	Yes
Syslog	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2
DC-in jack	Yes

Power

Specification	Value
Power over Ethernet (PoE)	Yes
AC input frequency	50 - 60 Hz
AC input voltage	100 - 240 V
Power consumption (max)	12 W

Design

Specification	Value
Placement	Ceiling, Wall
Product colour	White
Cable lock slot	Yes
Cable lock slot type	Kensington
Reset button	Yes
LED indicators	Yes

Antenna

Specification	Value
Antenna type	Internal
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Antennas quantity	6
Antenna gain level (max)	5 dBi

Certificates

Specification	Value
Certification	FCC, IC, CE

Weight & dimensions

Specification	Value
Width	200 mm
Depth	200 mm
Height	540 mm
Weight	40.64 g

Packaging content

Specification	Value
Cables included	LAN (RJ-45)
Mounting kit	Yes
Quick start guide	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 80 °C

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
