Managed AP Indoor Dual Band 11ax 574+2400Mbps 2T2R GbE PoE.af
4x3dBi ia
Model EWS356-FITEAN 655216011168
49 specifications
- Speed2400 Mbit/s
- Weight380 g
- ColourWhite
- 2.4 GHzYes
- Security algorithmsWPA2-Enterprise, WPA3
- Management protocolsSNTP
Overview
- Speed
- 2400 Mbit/s
- Weight
- 380 g
- Colour
- White
- 2.4 GHz
- Yes
- Security algorithms
- WPA2-Enterprise, WPA3
- Management protocols
- SNTP
- Brand
- EnGenius
- Category
- Wireless Access Point
- Model
- EWS356-FIT
- Part number
- EWS356-FIT
- EAN / UPC
- 655216011168, 4713361936487
- Also known as
- EnGenius Managed AP Indoor Dual Band 11ax 574+2400Mbps 2T2R GbE PoE.af 4x3dBi ia
Specifications
49 specifications in 14 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate | 2400 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
| Maximum data transfer rate (5 GHz) | 2400 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.11n, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | WPA2-Enterprise, WPA3 |
| MAC address filtering | Yes |
| IGMP snooping | Yes |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNTP |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Switch type | Managed |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 0 |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| DC voltage range | 12 V |
| Input current | 2 A |
| Power consumption (max) | 12.8 W |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Reset button | Yes |
| LED indicators | Yes |
Antenna
| Specification | Value |
|---|---|
| Antenna type | Internal |
| Antenna direction type | Omni-directional |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor frequency | 1000 MHz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 160 mm |
| Depth | 160 mm |
| Height | 33.2 mm |
| Weight | 380 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 266 mm |
| Package depth | 165 mm |
| Package height | 39 mm |
| Package weight | 570 g |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 353 mm |
| Master (outer) case length | 428 mm |
| Master (outer) case height | 311 mm |
| Master (outer) case gross weight | 12.2 kg |
| Products per master (outer) case | 20 pc(s) |
