EnGenius Outdoor PTP/PTMP Bridge, Wi-Fi 6 (11ax): Full Specifications

Overview

Processor: ARM Cortex-A53
Memory: 1024 MB
Weight: 1.91 kg
Colour: White
2.4 GHz: Yes
Security algorithms: 256-bit AES

Brand: EnGenius
Category: Wireless Access Point
Model: EOC655-C18
Part number: EOC655-C18
EAN / UPC: 655216011373, 4711488350223
Also known as: EnGenius Outdoor PTP/PTMP Bridge, Wi-Fi 6 (11ax), 2x2.5GbE , 30?°, at

Specifications

46 specifications in 15 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
6 GHz	No
Ethernet LAN data rates	10,100,1000,2500 Mbit/s

Security

Specification	Value
Security algorithms	256-bit AES
MAC address filtering	Yes
IP address filtering	Yes

Protocols

Specification	Value
DHCP server	Yes

Management features

Specification	Value
Syslog	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2

Power

Specification	Value
Power over Ethernet (PoE)	Yes
Power consumption (max)	21 W

Design

Specification	Value
Placement	Pole
Product colour	White
International Protection (IP) code	IP67

Antenna

Specification	Value
Antenna type	Internal & external
Antenna gain level (max)	18 dBi
Antenna connector type	N-type

Performance

Specification	Value
Built-in processor	Yes
Processor model	ARM Cortex-A53
Processor frequency	1000 MHz
Flash memory	32 MB
Internal memory	1024 MB

Certificates

Specification	Value
Compliance certificates	CB, RoHS, WEEE
Certification	FCC CE IC UKCA

Weight & dimensions

Specification	Value
Width	267 mm
Depth	227 mm
Height	82 mm
Weight	1.91 kg

Packaging data

Specification	Value
Package width	314 mm
Package depth	159 mm
Package height	450 mm
Package weight	4.02 kg

Packaging content

Specification	Value
Quantity per pack	1 pc(s)
PoE adapter included	Yes
Cables included	LAN (RJ-45)

Operational conditions

Specification	Value
Operating relative humidity (H-H)	0 - 90%
Operating temperature (T-T)	-10 - 60 °C
Storage temperature (T-T)	-40 - 80 °C
Storage relative humidity (H-H)	0 - 90%

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
Master (outer) case width	332 mm
Master (outer) case length	338 mm
Master (outer) case height	485 mm
Master (outer) case gross weight	8.81 kg
Products per master (outer) case	2 pc(s)
