EnGenius EOA7530 wireless access point 54 Mbit/s

EnGenius EOA7530 wireless access point 54 Mbit/s

Model EOA7530EAN 655216004245

22 specifications

Memory64 MB
Speed54 Mbit/s
2.4 GHzYes
Security algorithmsEAP-TLS, EAP-TTLS, WPA, WPA2
Ethernet LAN (RJ-45) ports1
Antenna gain level (max)5 dBi

See all specifications

Overview

Memory: 64 MB
Speed: 54 Mbit/s
2.4 GHz: Yes
Security algorithms: EAP-TLS, EAP-TTLS, WPA, WPA2
Ethernet LAN (RJ-45) ports: 1
Antenna gain level (max): 5 dBi

Brand: EnGenius
Category: Wireless Access Point
Model: EOA7530
Part number: EOA7530
EAN / UPC: 655216004245, 6552160042450
Also known as: EnGenius EOA7530 wireless access point 54 Mbit/s

Specifications

22 specifications in 9 groups

Features

Specification	Value
2.4 GHz	Yes
Maximum data transfer rate	54 Mbit/s
Ethernet LAN data rates	10,100 Mbit/s
Frequency band	2.4 GHz
Quality of Service (QoS) support	Yes
Receiver sensitivity	IEEE 802.11a -92dBm @ 6Mbps -73dBm @ 54Mbps IEEE 802.11g -94dBm @ 6Mbps -74dBm @ 54Mbp IEEE 802.11b -97dBm @ 1Mbps -92dBm @ 11Mbps Available Transmit Power (Average): Radio1 (WLAN1): IEEE 802.11a 28dBm @ 6~24Mbps 26dBm @ 36Mbps 24dBm @ 48Mbps 22dBm @ 54Mbps Radio2 (WLAN2): IEEE 802.11g 28dBm @ 6~24M

Security

Specification	Value
Security algorithms	EAP-TLS, EAP-TTLS, WPA, WPA2
MAC address filtering	Yes

Protocols

Specification	Value
DHCP server	Yes
DHCP client	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
WAN connection	Ethernet (RJ-45)
DC-in jack	Yes

Design

Specification	Value
LED indicators	Yes

Antenna

Specification	Value
Antenna gain level (max)	5 dBi
Antenna connector type	N-type

Performance

Specification	Value
Flash memory	8 MB
Internal memory	64 MB

Packaging content

Specification	Value
AC adapter included	Yes

Other features

Specification	Value
Power LED	Yes
Wireless technology	Wireless G
Connectivity LEDs	Yes
