Managed AP Indoor Dual Band 11ax 1148+2400Mbps 4T4R 2.5GbE PoE.at(+)
8x3dBi ia
Model ECW212LEAN 655216011700
59 specifications
- Weight570 g
- ColourWhite
- 2.4 GHzYes
- Security algorithmsWPA2-PSK, WPA3-PSK
- Ethernet LAN (RJ-45) ports1
- PlacementCeiling, Wall
Overview
- Weight
- 570 g
- Colour
- White
- 2.4 GHz
- Yes
- Security algorithms
- WPA2-PSK, WPA3-PSK
- Ethernet LAN (RJ-45) ports
- 1
- Placement
- Ceiling, Wall
- Brand
- EnGenius
- Category
- Wireless Access Point
- Model
- ECW212L
- Part number
- ECW212L
- EAN / UPC
- 655216011700, 4711488350421, 7071320166083
- Also known as
- EnGenius Managed AP Indoor Dual Band 11ax 1148+2400Mbps 4T4R 2.5GbE PoE.at(+) 8x3dBi ia
Specifications
59 specifications in 13 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | No |
| Maximum data transfer rate (2.4 GHz) | 1200 Mbit/s |
| Maximum data transfer rate (5 GHz) | 2400 Mbit/s |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Frequency band | 2.4 - 5.85 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u |
| Number of users | 128 user(s) |
| Bluetooth | No |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Spatial streams | 4 x 4 |
| Spread spectrum method | OFDM, OFDMA |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Wi-Fi roaming | Yes |
| Fast roaming | Yes |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
| Band steering | Yes |
| Maximum Tx power (2.4 GHz) | 23 dBmW |
| Maximum Tx power (5 GHz) | 23 dBmW |
Security
| Specification | Value |
|---|---|
| Security algorithms | WPA2-PSK, WPA3-PSK |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 0 |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| DC voltage range | 12 V |
| Input current | 2 A |
| Power consumption (max) | 17 W |
Design
| Specification | Value |
|---|---|
| Placement | Ceiling, Wall |
| Product colour | White |
| LED indicators | PoE, Power |
Antenna
| Specification | Value |
|---|---|
| Antenna type | Internal |
| Antenna direction type | Omni-directional |
| Antenna features | Integrated antenna |
| Antennas quantity | 8 |
| Antenna gain level (max) | 5 dBi |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), UKCA |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 205 mm |
| Depth | 205 mm |
| Height | 33 mm |
| Weight | 570 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 247 mm |
| Package depth | 247 mm |
| Package height | 87 mm |
| Package weight | 870 g |
Packaging content
| Specification | Value |
|---|---|
| Mounting kit | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 80 °C |
| Storage relative humidity (H-H) | 0 - 90% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 460 mm |
| Master (outer) case length | 520 mm |
| Master (outer) case height | 270 mm |
| Master (outer) case gross weight | 10.1 kg |
| Products per master (outer) case | 10 pc(s) |
