Managed AP Indoor Dual Band 11ax 574+2400Mbps 2T2R GbE PoE.af
4x3dBi ia
Model ECW210LEAN 655216011694
63 specifications
- ProcessorARM Cortex-A53
- Speed2400 Mbit/s
- Weight380 g
- ColourWhite
- 2.4 GHzYes
- Security algorithmsWPA2-PSK, WPA3-PSK
Overview
- Processor
- ARM Cortex-A53
- Speed
- 2400 Mbit/s
- Weight
- 380 g
- Colour
- White
- 2.4 GHz
- Yes
- Security algorithms
- WPA2-PSK, WPA3-PSK
- Brand
- EnGenius
- Category
- Wireless Access Point
- Model
- ECW210L
- Part number
- ECW210L
- EAN / UPC
- 655216011694, 4711488350414, 7071320166076
- Also known as
- EnGenius Managed AP Indoor Dual Band 11ax 574+2400Mbps 2T2R GbE PoE.af 4x3dBi ia
Specifications
63 specifications in 13 groups
Features
| Specification | Value |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | No |
| Maximum data transfer rate | 2400 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 600 Mbit/s |
| Maximum data transfer rate (5 GHz) | 2400 Mbit/s |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Frequency band | 2.4 - 5.85 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Number of users | 128 user(s) |
| Bluetooth | No |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Spatial streams | 2 x 2 |
| Spread spectrum method | DSSS, OFDM, OFDMA |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Wi-Fi roaming | Yes |
| Fast roaming | Yes |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
| Quality of Service (QoS) support | Yes |
| Maximum Tx power (2.4 GHz) | 21 dBmW |
| Maximum Tx power (5 GHz) | 21 dBmW |
Security
| Specification | Value |
|---|---|
| Security algorithms | WPA2-PSK, WPA3-PSK |
| MAC address filtering | Yes |
| Service Set Identifier (SSID) features | Hidden SSID |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 0 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| DC voltage range | 12 V |
| Input current | 1.5 A |
| Power consumption (max) | 10.7 W |
Design
| Specification | Value |
|---|---|
| Placement | Ceiling, Wall |
| Product colour | White |
Antenna
| Specification | Value |
|---|---|
| Antenna type | Internal |
| Antenna direction type | Omni-directional |
| Antenna features | Integrated antenna |
| Antennas quantity | 4 |
| Antenna gain level (max) | 7 dBi |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor model | ARM Cortex-A53 |
| Processor frequency | 1000 MHz |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), UKCA |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 160 mm |
| Depth | 160 mm |
| Height | 30 mm |
| Weight | 380 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 266 mm |
| Package depth | 165 mm |
| Package height | 39 mm |
| Package weight | 500 g |
Packaging content
| Specification | Value |
|---|---|
| Mounting kit | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 80 °C |
| Storage relative humidity (H-H) | 0 - 90% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 353 mm |
| Master (outer) case length | 428 mm |
| Master (outer) case height | 311 mm |
| Master (outer) case gross weight | 12.2 kg |
| Products per master (outer) case | 20 pc(s) |
