D-Link DWL-8710AP wireless access point 1167 Mbit/s White Power over Ethernet (PoE)

D-Link DWL-8710AP wireless access point 1167 Mbit/s White Power over Ethernet (PoE)

Model DWL-8710APPart no. DWL-8710AP-BUNEAN 790069423802

58 specifications

Speed1167 Mbit/s
Weight2.05 kg
ColourWhite
2.4 GHzYes
Ethernet LAN (RJ-45) ports2
PlacementPole, Wall

See all specifications

Overview

Speed: 1167 Mbit/s
Weight: 2.05 kg
Colour: White
2.4 GHz: Yes
Ethernet LAN (RJ-45) ports: 2
Placement: Pole, Wall

Brand: D-Link
Category: Wireless Access Point
Model: DWL-8710AP
Part numbers: DWL-8710AP-BUN, DWL-8710AP, DWL-8710AP?KIT
EAN / UPC: 790069423802, 790069423277, 790069423284, 790069423291
Also known as: D-Link DWL-8710AP wireless access point 1167 Mbit/s White Power over Ethernet (PoE)

Specifications

58 specifications in 13 groups

Features

Specification	Value
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	1167 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Ethernet LAN data rates	1000 Mbit/s
Frequency band	2.4 - 2.4835, 5.18 - 5.24, 5.28 - 5.32, 5.5 - 5.7, 5.745 - 5.825 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3at
Channels quantity	165 channels
Automatic channel selection	Yes
VLAN support	Yes
Wireless isolation	Yes

Security

Specification	Value
Security algorithms	AES, SNMP, SSH, SSID, TKIP, WPA, WPA2
MAC address filtering	Yes
Number of SSID supported	32

Management features

Specification	Value
Web-based management	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	0

Power

Specification	Value
Power over Ethernet (PoE)	Yes
Power consumption (max)	16.5 W

Design

Specification	Value
Placement	Pole, Wall
Product colour	White
Housing material	Metal, Polycarbonate (PC)
International Protection (IP) code	IP67
Internal	No

Antenna

Specification	Value
Antenna type	Omni-directional
Antennas quantity	4
Antenna gain level (max)	7 dBi
Antenna connector type	N-type
Number of connectors	4

Technical details

Specification	Value
Master (outer) cases per pallet (air)	18 pc(s)
Master (outer) cases per pallet (sea)	30 pc(s)
Pallet gross length	110 cm
Pallet gross weight (air)	167.8 kg
Pallet gross weight (sea)	269.7 kg
Pallet gross width	120 cm
Pallet height (air)	107.7 cm
Pallet height (sea)	170.5 cm
Products per pallet (air)	36 pc(s)
Products per pallet (sea)	60 pc(s)
Products per shipping (inner) case	2 pc(s)
Shipping (inner) case gross weight	8.49 kg
Shipping (inner) case height	31.4 cm
Shipping (inner) case length	37.2 cm
Shipping (inner) case net weight	7.75 kg
Shipping (inner) case width	30.7 cm

Certificates

Specification	Value
Certification	CE, EN 301 893 V1.7.1 (2012-06) (DFS/TPC), EN 300, 328 V1.8.1 (2012-06), FCC, IC, cUL, C-Tick, NCC, Wi-Fi, LVD, BSMI

Weight & dimensions

Specification	Value
Width	250 mm
Depth	45 mm
Height	220 mm
Weight	2.05 kg

Packaging data

Specification	Value
Package width	301 mm
Package depth	369 mm
Package height	147 mm
Package weight	3.87 kg

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-30 - 60 °C
Storage temperature (T-T)	-30 - 70 °C

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
